Sony VPL-S900E - GA GB BOARD; GA Board Resistors (R7019-R7129)

6-17
VPL-S900E, VPL-S900M, VPL-S900U
Rf.NO. PART NO. DESCRIPTION REMARK Rf.NO. PART NO. DESCRIPTION REMARK
C7052 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7054 1-115-784-11 ELECT 270µF 20% 25V
C7055 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7056 1-128-526-11 ELECT 100µF 20% 10V
C7057 1-107-823-11 CERAMIC CHIP 0.47µF 10% 16V
C7059 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7060 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7061 1-107-909-11 ELECT 47µF 20% 16V
C7062 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7063 1-115-755-11 ELECT 180µF 20% 16V
C7064 1-115-734-11 ELECT 680µF 20% 10V
C7065 1-107-792-11 CERAMIC 100PF 5% 1KV
C7066 1-164-004-11 CERAMIC CHIP 0.1µF 10% 25V
C7067 1-107-909-11 ELECT 47µF 20% 16V
C7068 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C7069 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C7070 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C7071 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C7072 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C7073 1-129-720-00 FILM 0.033µF 5% 630V
C7074 1-115-339-11 CERAMIC CHIP 0.1µF 10% 50V
<CONNECTOR>
CN7001 * 1-691-960-11 PIN, CONNECTOR (PC BOARD) 3P
CN7002 * 1-564-507-11 PLUG, CONNECTOR 4P
CN7003 * 1-778-373-11 PIN, CONNECTOR (PC BOARD)
CN7004 * 1-778-373-11 PIN, CONNECTOR (PC BOARD)
<DIODE>
D7001 8-719-059-23 DIODE P6KE200AG23
D7002 8-719-947-06 DIODE RGP10JPKG23
D7003 8-719-302-43 DIODE EL1Z
D7004 8-719-104-34 DIODE 1S2836
D7005 8-719-106-71 DIODE RD12M-B2
D7006 1-803-136-11 VARISTOR ZP2600
D7007 8-719-022-97 DIODE D2S4MF
D7009 8-719-510-41 DIODE D10SC9M
D7010 8-719-051-96 DIODE FMG-G2CS
D7011 8-719-510-41 DIODE D10SC9M
D7012 8-719-050-21 DIODE FCQ20A04
D7013 8-719-510-13 DIODE D10SC4MR
D7015 8-719-510-41 DIODE D10SC9M
D7020 8-719-914-43 DIODE DAN202K
D7021 8-719-055-30 DIODE D1FS4A-TA
D7022 8-719-055-30 DIODE D1FS4A-TA
D7023 8-719-055-30 DIODE D1FS4A-TA
D7024 8-719-055-30 DIODE D1FS4A-TA
D7025 8-719-510-41 DIODE D10SC9M
D7026 8-719-510-41 DIODE D10SC9M
D7027 8-719-510-41 DIODE D10SC9M
D7028 8-719-050-21 DIODE FCQ20A04
D7029 8-719-055-30 DIODE D1FS4A-TA
D7030 8-719-068-71 DIODE PTZ-TE25-13A
D7031 8-719-068-71 DIODE PTZ-TE25-13A
D7101 8-719-106-80 DIODE RD13M-B2
<IC>
IC7002 8-759-157-17 IC PQ05SZ1U
IC7003 8-759-485-64 IC UCC2801N
IC7005 8-759-388-23 IC TL431BCDR2
IC7006 8-759-487-72 IC TOP222Y-BB
IC7007 8-759-485-63 IC MAX1626ESA-TE2
IC7010 8-759-485-63 IC MAX1626ESA-TE2
IC7012 8-759-701-79 IC NJM7812FA
IC7013 8-759-506-12 IC PQ12RF1
IC7014 8-759-506-12 IC PQ12RF1
<COIL>
L7001 1-406-975-21 INDUCTOR 47µH
L7002 1-406-980-61 INDUCTOR 330µH
L7003 1-406-974-61 INDUCTOR 33µH
L7004 1-406-971-51 INDUCTOR 10µH
L7005 1-412-531-31 INDUCTOR 33µH
L7006 1-406-977-61 INDUCTOR 100µH
L7007 1-412-531-31 INDUCTOR 33µH
L7010 1-406-656-21 INDUCTOR 3.3µH
L7011 1-406-658-21 INDUCTOR 6.8µH
<PHOTO COUPLER>
PH7001 8-749-010-64 PHOTO COUPLER PC123F2
PH7002 8-749-010-64 PHOTO COUPLER PC123F2
PH7003 8-749-013-16 IC PC357N2T
<IC LINK>
PS7001 ! 1-533-282-21 LINK, IC (2A)
PS7003 ! 1-576-124-21 LINK, IC (1A)
PS7004 ! 1-216-296-91 SHORT 0
PS7005 ! 1-576-124-21 LINK, IC (1A)
PS7007 ! 1-576-124-21 LINK, IC (1A)
PS7010 ! 1-533-282-21 LINK, IC (2A)
PS7011 ! 1-533-282-21 LINK, IC (2A)
PS7013 ! 1-533-282-21 LINK, IC (2A)
<TRANSISTOR>
Q7004 8-729-031-13 TRANSISTOR SI-9430DY-T1
Q7007 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7010 8-729-230-49 TRANSISTOR 2SC2712-YG
Q7013 8-729-042-96 TRANSISTOR 2SK2677F-02
Q7015 8-729-031-13 TRANSISTOR SI-9430DY-T1
Q7018 8-729-042-96 TRANSISTOR 2SK2677F-02
<RESISTOR>
R7001 1-217-418-61 FUSIBLE 0.47 10% 1/2W F
R7002 1-216-009-91 RES,CHIP 22 5% 1/10W
R7003 1-218-191-11 METAL OXIDE 0.1 5% 1W F
R7005 1-216-295-91 SHORT 0
R7016 1-216-069-00 RES,CHIP 6.8K 5% 1/10W
R7017 1-216-079-00 RES,CHIP 18K 5% 1/10W
R7018 1-216-101-00 RES,CHIP 150K 5% 1/10W
GB
