Sony VPL-VW80 - Front View; Side View

84
Front view
Side view
Ceiling
The bottom
surface of the
mount bracket
Center of the
supporting pole
Center of the lens
150 (6)
75 (3)
175 (7)
93.5 (3
3
/
4
)
235 (9
3
/
8
) 235 (9
3
/
8
)
470 (18
5
/
8
)
Center of the lens
Front of the cabinet
202.3 (8) 130 (5
1
/
8
)
247.3 (9
3
/
4
) 235.1 (9
3
/
8
)
482.4 (19)
