Looking at the controls
See pages in ( ) for more details.
The recorder
A x/CHARGE button (7)(10)(29)(39)
B Display window (14)(23)
C REC indicator (18)
D DC IN 3V jack (at the rear) (6)(9)(39)
E Jog lever (10)(15)(23)(32)
F i (headphones)/LINE OUT jack
(9)(21)(28)
G MIC (PLUG IN POWER) jack (15)
H LINE IN (OPTICAL) jack (6)(13)
I HOLD switch (27)
J N (play) button (8)(10)(36)
K X (pause) button (8)(10)(20)(33)(35)
L T MARK button (29)
M REC (record) switch (7)
N Battery compartment (at the rear) (39)
O VOL +/– button (10)(33)
P OPEN switch (7)(9)
Q END SEARCH button (8)(33)
R ./> (search /AMS) button
(8)(10)(31)(33)(36)
S SYNCHRO REC (synchro-recording)
switch (14)
A
B
C
E
D
F
G
H
I
M
J
K
L
N
O
S
P
Q
R
