20
WM-EX527
MAIN
SECTION 8
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
* A-3021-287-A MAIN BOARD, COMPLETE
*********************
< CAPACITOR >
C101 1-107-520-11 TANTALUM CHIP 33uF 20% 2.5V
C102 1-115-156-11 CERAMIC CHIP 1uF 10V
C103 1-115-156-11 CERAMIC CHIP 1uF 10V
C104 1-115-156-11 CERAMIC CHIP 1uF 10V
C107 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C108 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C109 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C133 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C201 1-107-520-11 TANTALUM CHIP 33uF 20% 2.5V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C208 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C209 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C233 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C301 1-119-663-11 TANTALUM CHIP 47uF 20% 2.5V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-125-926-95 TANTALUM CHIP 4.7uF 20% 2.5V
C304 1-115-156-11 CERAMIC CHIP 1uF 10V
C305 1-126-236-11 ELECT 330uF 20% 2V
C306 1-109-935-11 TANTALUM CHIP 4.7uF 20% 4V
C307 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C308 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C309 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C310 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C312 1-115-156-11 CERAMIC CHIP 1uF 10V
C313 1-109-935-11 TANTALUM CHIP 4.7uF 20% 4V
C314 1-135-187-21 TANTALUM CHIP 2.2uF 20% 4V
C316 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C319 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C320 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C321 1-115-416-11 CERAMIC CHIP 0.001uF 5% 25V
C322 1-125-899-11 TANTALUM CHIP 220uF 20% 4V
C323 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C601 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
When indicating parts by reference
number, please include the board.
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C701 1-119-750-11 TANTALUM CHIP 22uF 20% 6.3V
C702 1-104-851-11 TANTALUM CHIP 10uF 20% 10V
C703 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C708 1-115-156-11 CERAMIC CHIP 1uF 10V
C709 1-115-156-11 CERAMIC CHIP 1uF 10V
C711 1-115-156-11 CERAMIC CHIP 1uF 10V
< COMPOSITION CIRCUIT BLOCK >
CB301 1-127-575-21 CAP, CHIP CERAMIC 470PF SL
< DIODE >
D701 8-719-404-50 DIODE MA111-TX
D702 8-719-072-70 DIODE MA2ZD14001S0
D703 8-719-077-09 LED CL-196HR-CD-T (BATT)
D705 8-719-077-09 LED CL-196HR-CD-T (AVLS)
D706 8-719-077-09 LED CL-196HR-CD-T (BL SKIP/s)
D709 8-719-068-83 DIODE MAZL068D0LS0-TX/L
D710 8-719-422-58 DIODE MA8062
D711 8-719-422-58 DIODE MA8062
< FERRITE BEAD >
FB101 1-469-125-21 FERRITE
FB201 1-469-125-21 FERRITE
< IC >
IC301 8-759-579-12 IC TA2123AF (EL)
IC601 8-759-356-46 IC MM1279XVBE
IC701 8-759-651-61 IC uPD789166GB-510-8ES
IC702 8-759-566-77 IC XC6371C251PL
IC703 8-759-665-68 IC PST9016NL
IC704 8-759-387-31 IC TC75S55F (TE85R)
< JACK >
J301 1-779-867-81 JACK (i)
< RESISTOR >
JC101 1-216-864-11 SHORT CHIP 0
JC201 1-216-864-11 SHORT CHIP 0
