WM-EX621
10
3-6. ORNAMENT, REEL
3-7. HOLDER (FS) ASSY
2
Cla
w
4
Two claws
1
Two claws
3
Boss
5
Ornament,reel
9
Remove soldering from
six head flexible boards.
0
Remove the holder (FS)
assy in the direction of
the arrow.
8
Shielded sheet
1
Two screws
(M1.4
×
1.4)
3
Lock Lever (B)
2
Shaft
7
Bracket (cassette) assy
6
Shaft
4
Screw (M1.4)
5
Shaft
