23
WM-EX621
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
The components identified by mark ! or
dotted line with mark ! are critical for
safety.Replace only with part number
specified.
When indicating parts by reference number,
please include the board name.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
SECTION 8
ELECTRICAL PARTS LIST
• Abbreviation
FR : French model
EE : East European model
CH : Chinese model
HK : Hong Kong model
KR : Korean model
JE : Tourist model
* A-3021-537-A MAIN BOARD, COMPLETE
(AEP,CH,EE,HK,JEW,KR,UK)
**********************
* A-3021-538-A MAIN BOARD, COMPLETE (FR)
*************************
3-032-323-01 PAPER (A), SHIELD
< CAPACITOR >
C101 1-107-520-11 TANTAL. CHIP 33uF 20.00% 2.5V
C102 1-115-156-11 CERAMIC CHIP 1uF 10V
C103 1-115-156-11 CERAMIC CHIP 1uF 10V
C104 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C107 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C108 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C109 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C111 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C201 1-107-520-11 TANTAL. CHIP 33uF 20.00% 2.5V
C202 1-115-156-11 CERAMIC CHIP 1uF 10V
C203 1-115-156-11 CERAMIC CHIP 1uF 10V
C204 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C207 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C208 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C209 1-164-677-11 CERAMIC CHIP 0.033uF 10.00% 16V
C211 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C301 1-119-663-11 TANTAL. CHIP 47uF 20.00% 2.5V
C302 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C303 1-125-926-95 TANTAL. CHIP 4.7uF 20.00% 2.5V
C304 1-115-156-11 CERAMIC CHIP 1uF 10V
C305 1-126-236-11 ELECT 330uF 20.00% 2V
C306 1-109-935-11 TANTAL. CHIP 4.7uF 20.00% 4V
C307 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C308 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C309 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C310 1-135-149-11 TANTALUM CHIP 2.2uF 20% 10V
C311 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C312 1-115-156-11 CERAMIC CHIP 1uF 10V
C313 1-109-935-11 TANTAL. CHIP 4.7uF 20.00% 4V
C314 1-135-187-21 TANTAL. CHIP 2.2uF 20.00% 4V
C315 1-135-187-21 TANTAL. CHIP 2.2uF 20.00% 4V
C316 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C319 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C320 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C321 1-115-416-11 CERAMIC CHIP 0.001uF 5.00% 25V
C322 1-109-937-11 TANTAL. CHIP 6.8uF 20.00% 2.5V
C323 1-115-412-11 CERAMIC CHIP 680PF 5.00% 25V
C325 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
(AEP,CH,EE,HK,JEW,KR,UK)
C601 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C603 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C604 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C609 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C701 1-119-750-11 TANTAL. CHIP 22uF 20.00% 6.3V
C702 1-104-851-11 TANTAL. CHIP 10uF 20.00% 10V
C703 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C704 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C705 1-115-156-11 CERAMIC CHIP 1uF 10V
C706 1-115-156-11 CERAMIC CHIP 1uF 10V
C707 1-115-156-11 CERAMIC CHIP 1uF 10V
C708 1-115-156-11 CERAMIC CHIP 1uF 10V
C709 1-115-156-11 CERAMIC CHIP 1uF 10V
C711 1-115-156-11 CERAMIC CHIP 1uF 10V
C712 1-115-156-11 CERAMIC CHIP 1uF 10V
CB301 1-127-575-11 CAP, CHIP CERAMIC 470PF SL
CB303 1-127-576-11 CAP, CHIP CERAMIC 22000PF B
< DIODE >
D701 8-719-404-50 DIODE MA111-TX
D702 8-719-049-09 DIODE 1SS367-T3SONY
D709 8-719-068-83 DIODE MAZL068D0LS0-TX/L
D710 8-719-422-58 DIODE MA8062-TX
D711 8-719-422-58 DIODE MA8062-TX
< FERRITE BEAD >
FB101 1-469-125-21 FERRITE 0UH (AEP,CH,EE,HK,JEW,KR,UK)
FB201 1-469-125-21 FERRITE 0UH (AEP,CH,EE,HK,JEW,KR,UK)
< IC >
IC301 8-759-579-12 IC TA2123AF (EL)
IC601 8-759-356-46 IC MM1279XVBE
IC701 6-800-619-01 IC ML63512-129TBZ060
IC702 8-759-566-77 IC XC6371C251PL
IC703 8-759-430-08 IC PST9008NL
IC704 8-759-280-84 IC S-81211SG-QA-T1
MAIN
