Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
24
WM-EX621
< JACK >
J301 1-779-867-11 JACK (i)
< JANPER >
JC114 1-216-864-11 METAL CHIP 0 5% 1/16W
< COIL >
L701 1-412-032-11 INDUCTOR CHIP 100uH
< PHOTO INTERRUPTER >
PH701 8-749-014-43 PHOTO REFLECTOR PR-20-T
< TRANSISTOR >
Q301 8-729-800-71 TRANSISTOR 2SB1295-UL6-TB
Q302 8-729-423-75 TRANSISTOR XN1116-TX
Q303 8-729-423-75 TRANSISTOR XN1116-TX
Q304 8-729-421-23 TRANSISTOR XN1216-TX
Q306 8-729-421-23 TRANSISTOR XN1216-TX
Q603 8-729-420-50 TRANSISTOR UN5215-(TX)
Q604 8-729-420-50 TRANSISTOR UN5215-(TX)
Q701 8-729-230-72 TRANSISTOR 2SA1362-YG-ER
Q702 8-729-420-50 TRANSISTOR UN5215-(TX)
< RESISTOR >
R101 1-216-849-11 METAL CHIP 220K 5% 1/16W
R102 1-216-839-11 METAL CHIP 33K 5% 1/16W
R103 1-216-811-11 METAL CHIP 150 5% 1/16W
R104 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R105 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R106 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R107 1-216-837-11 METAL CHIP 22K 5% 1/16W
R108 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R109 1-216-821-11 METAL CHIP 1K 5% 1/16W
R110 1-216-837-11 METAL CHIP 22K 5% 1/16W
R111 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R112 1-216-819-11 METAL CHIP 680 5% 1/16W
(FR)
R112 1-218-839-11 METAL CHIP 470 0.5% 1/10W
(AEP,CH,EE,HK,JEW,KR,UK)
R113 1-216-853-11 METAL CHIP 470K 5% 1/16W
R114 1-216-853-11 METAL CHIP 470K 5% 1/16W
R115 1-216-815-11 METAL CHIP 330 5% 1/16W
R150 1-216-811-11 METAL CHIP 150 5% 1/16W
(FR)
R201 1-216-849-11 METAL CHIP 220K 5% 1/16W
R202 1-216-839-11 METAL CHIP 33K 5% 1/16W
R203 1-216-811-11 METAL CHIP 150 5% 1/16W
R204 1-216-831-11 METAL CHIP 6.8K 5% 1/16W
R205 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R206 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R207 1-216-837-11 METAL CHIP 22K 5% 1/16W
R208 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R209 1-216-821-11 METAL CHIP 1K 5% 1/16W
R210 1-216-837-11 METAL CHIP 22K 5% 1/16W
R211 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R212 1-216-819-11 METAL CHIP 680 5% 1/16W
(FR)
R212 1-218-839-11 METAL CHIP 470 0.5% 1/10W
(AEP,CH,EE,HK,JEW,KR,UK)
R213 1-216-853-11 METAL CHIP 470K 5% 1/16W
R214 1-216-853-11 METAL CHIP 470K 5% 1/16W
R215 1-216-815-11 METAL CHIP 330 5% 1/16W
R250 1-216-811-11 METAL CHIP 150 5% 1/16W
(FR)
R302 1-216-849-11 METAL CHIP 220K 5% 1/16W
R303 1-216-833-11 METAL CHIP 10K 5% 1/16W
R304 1-216-835-11 METAL CHIP 15K 5% 1/16W
R305 1-216-837-11 METAL CHIP 22K 5% 1/16W
R306 1-216-793-11 RES-CHIP 4.7 5% 1/16W
R307 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R308 1-216-851-11 METAL CHIP 330K 5% 1/16W
R601 1-216-837-11 METAL CHIP 22K 5% 1/16W
R602 1-216-809-11 METAL CHIP 100 5% 1/16W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R604 1-216-821-11 METAL CHIP 1K 5% 1/16W
R701 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R702 1-216-861-11 METAL CHIP 2.2M 5% 1/16W
R703 1-216-853-11 METAL CHIP 470K 5% 1/16W
R704 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R705 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R706 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R707 1-218-915-11 METAL CHIP 680K 0.5% 1/10W
R708 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R709 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R710 1-216-853-11 METAL CHIP 470K 5% 1/16W
R711 1-216-853-11 METAL CHIP 470K 5% 1/16W
R712 1-216-853-11 METAL CHIP 470K 5% 1/16W
R713 1-216-841-11 METAL CHIP 47K 5% 1/16W
R714 1-216-803-11 METAL CHIP 33 5% 1/16W
R717 1-216-821-11 METAL CHIP 1K 5% 1/16W
R718 1-216-821-11 METAL CHIP 1K 5% 1/16W
R720 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R721 1-218-839-11 METAL CHIP 470 0.5% 1/10W
R722 1-218-855-11 METAL CHIP 2.2K 0.5% 1/10W
R723 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R724 1-218-875-11 METAL CHIP 15K 0.5% 1/10W
R726 1-216-821-11 METAL CHIP 1K 5% 1/16W
R731 1-216-833-11 METAL CHIP 10K 5% 1/16W
R732 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R733 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R734 1-218-851-11 METAL CHIP 1.5K 0.5% 1/10W
R735 1-218-871-11 METAL CHIP 10K 0.5% 1/10W
R736 1-218-867-11 METAL CHIP 6.8K 0.5% 1/10W
R738 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R739 1-218-911-11 METAL CHIP 470K 0.5% 1/10W
R801 1-216-825-11 METAL CHIP 2.2K 5% 1/16W
R802 1-216-857-11 METAL CHIP 1M 5% 1/16W
R832 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
< COMPOSITION CIRCUIT BLOCK >
RB601 1-234-243-11 RES, NETWORK 220K (3216)
< VARIABLE RESISTOR >
RV301 1-225-684-11 RES, VAR, CARBON 30K/30K (VOL)
RV601 1-225-254-11 RES, ADJ, CARBON 2.2K (TAOE SPEED)
MAIN
