— 2 —
TABLE OF CONTENTS
Notes on chip component replacement
• Never reuse a disconnected chip component.
• Notice that the minus side of a tantalum capacitor may be
damaged by heat.
Flexible Circuit Board Repairing
• Keep the temperature of soldering iron around 270˚C
during repairing.
• Do not touch the soldering iron on the same conductor of the
circuit board (within 3 times).
• Be careful not to apply force on the conductor when soldering
or unsoldering.
SECTION 1
GENERAL
This section is extracted
from instruction manual.
1. GENERAL ·········································································· 2
2. SERVICE NOTE ······························································· 3
3. DISASSEMBLY
3-1. Main Assembly······························································ 4
3-2. Chassis Sub Assy··························································· 5
3-3. Main Board and Mechanism Deck ································ 5
3-4. Belt ················································································ 6
3-5. Head, Magnetic (HP901)··············································· 6
4. MECHANICAL ADJUSTMENT ·································· 7
5. ELECTRICAL ADJUSTMENT ···································· 7
6. DIAGRAMS
6-1. IC Block Diagrams ······················································ 10
6-2. Block Diagram ···························································· 11
6-3. Schematic Diagram ····················································· 13
6-4. Printed Wiring Board··················································· 15
6-5. IC Pin Function Description········································ 17
7. MEXPLODED VIEWS
7-1. Cabinet Assy Section ··················································· 18
7-2. Main Board Section····················································· 19
7-3. Mechanism Deck Section-1
(MF-WMFS220-114) ·················································· 20
7-4. Mechanism Deck Section-2
(MF-WMFS220-114) ·················································· 21
8. ELECTRICAL PPARTS LIST ···································· 22
