— 6 —
3-4. BELT
Reel/Capstan motor
Capstan wheel assy(SP)
Belt threading
Belt
Belt
3-5. HEAD, MAGNETIC (HP901)
1
Two screws (M1.4)
2
Head, magnetic (HP901)
