Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 24 —
R208 1-216-795-11 RES-CHIP 6.8 5% 1/16W
R209 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R301 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R302 1-216-234-00 RES-CHIP 33K 5% 1/8W
R303 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R304 1-216-833-11 RES-CHIP 10K 5% 1/16W
R305 1-216-246-00 RES-CHIP 100K 5% 1/8W
R306 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R501 1-216-833-11 RES-CHIP 10K 5% 1/16W
R502 1-216-847-11 METAL CHIP 150K 5% 1/16W
R503 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R504 1-216-819-11 METAL CHIP 680 5% 1/16W
R601 1-216-821-11 METAL CHIP 1K 5% 1/16W
R602 1-216-821-11 METAL CHIP 1K 5% 1/16W
R603 1-216-833-11 RES-CHIP 10K 5% 1/16W
R604 1-216-845-11 METAL CHIP 100K 5% 1/16W
R605 1-216-821-11 METAL CHIP 1K 5% 1/16W
R606 1-216-833-11 RES-CHIP 10K 5% 1/16W
R607 1-216-198-91 RES-CHIP 1K 5% 1/8W
R701 1-216-833-11 RES-CHIP 10K 5% 1/16W
R703 1-216-833-11 RES-CHIP 10K 5% 1/16W
R704 1-216-841-11 METAL CHIP 47K 5% 1/16W
R705 1-216-845-11 METAL CHIP 100K 5% 1/16W
R706 1-216-845-11 METAL CHIP 100K 5% 1/16W
R709 1-216-833-11 RES-CHIP 10K 5% 1/16W
R710 1-216-833-11 RES-CHIP 10K 5% 1/16W
R711 1-216-833-11 RES-CHIP 10K 5% 1/16W
R712 1-216-833-11 RES-CHIP 10K 5% 1/16W
R713 1-216-833-11 RES-CHIP 10K 5% 1/16W
R714 1-216-833-11 RES-CHIP 10K 5% 1/16W
R715 1-216-833-11 RES-CHIP 10K 5% 1/16W
R716 1-216-833-11 RES-CHIP 10K 5% 1/16W
R717 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R718 1-216-845-11 METAL CHIP 100K 5% 1/16W
R719 1-216-847-11 METAL CHIP 150K 5% 1/16W
R721 1-216-845-11 METAL CHIP 100K 5% 1/16W
R723 1-216-226-00 RES-CHIP 15K 5% 1/8W
R724 1-216-845-11 METAL CHIP 100K 5% 1/16W
R725 1-216-805-11 METAL CHIP 47 5% 1/16W
< VARIABLE RESISTOR >
RV301 1-225-184-11 RES, VAR, CARBON 10K/10K (VOLUME)
RV601 1-241-916-11 RES, ADJ, CARBON 4.7K
< SWITCH >
S302 1-771-586-41 SWITCH, SLIDE (AVLS)
S303 1-762-742-61 SWITCH, DETECTION (SMALL TYPE)
S304 1-762-624-11 SWITCH, SLIDE (LOCAL/DX)
S701 1-771-586-41 SWITCH, SLIDE (HOLD)
< TRANSFORMER >
T1 1-406-694-11 COIL, AM IFT
< THERMISTOR >
TH601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X1 1-781-137-11 FILTER ASSY, CERAMIC
X701 1-577-262-11 VIBRATOR, CRYSTAL 75kHz
**************************************************************
* 1-676-497-11 HEADPHONE BOARD
*****************
< JACK >
J301 1-565-376-11 JACK (PHONES)
**************************************************************
MISCELLANEOUS
**************
HP901 1-500-517-11 HEAD, MAGNETIC (PLAYBACK)
M601 1-763-073-11 MOTOR (REEL/CAPSTAN)(WITH PULLEY)
**************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
3-022-755-11 CLIP, BELT
8-953-284-91 HEADPHONE MDR-W014LP
3-868-005-11 MANUAL, INSTRUCTION
(ENGLISH/SPANISH/FRENCH)
3-868-005-21 MANUAL, INSTRUCTION
(ENGLISH/SPANISH/FRENCH/PORTUGUESE)
**************************************************************
**************
HARDWARE LIST
**************
#1 7-624-101-04 STOP RING 1.2 (E TYPE)
#2 7-626-311-81 SPRING-PIN 1.6X18
#3 7-627-850-67 SCREW,PRECISION +P 1.4X4
MAIN HEADPHONE
WM-FS220
Sony Corporation
Personal Audio Division Company
2000B16043-1
Printed in Japan © 2000.2
Published by General Engineering Dept.
9-927-682-11
