Sony WM-FS220 - Page 9

— 9 —
[MAIN BOARD]
— Component side —
— Conductor side —
CT1
L1
AM Tracking
Adjustment
T1
AM IF
Adjustment
CT2
L3
FM Tracking
Adjustment
L4
FM Frequency
Coverage Adjustment
L2
AM Frequency
Coverage Adjustmen
t
TP22
FM IN
TP30
VT
