3
WM-FS555/FS556
2 Two screws
(B1.7 × 8)
1 Open the “lid, Cassette”
H/P board
5
3 Claws
Cabinet (rear) sub ASSY
Chassis
4
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CHASSIS, H/P BOARD
2-2. MAIN BOARD
z
The equipment can be removed using the following procedure.
Main boardChassis, H/P board
Mechanism deck Belt, Capstan/reel motor (M601),
Magnetic head (playback) (HP901)
Set
1 Remove solder
(four places)
3 Screw
(WH M1.4)
2 Remove solder
(six places)
4 Claws
5
Main boar
To Next Page
