Sony WM-FX193 Service Manual

– 21 –
NOTE :
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms
METAL : Metal-film resistor
METAL OXIDE :Metal oxide-film resistor
F : nonflammable
• Items marked “ * ”are not stocked since
they are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• SEMICONDUCTORS
In each case, u : µ , for example :
uA.... : µ A.... , uPA.... : µ PA....
uPB.... : µ PB.... , uPC.... : µ PC....
uPD.... : µ PD....
• CAPACITORS
uF : µ F
• COILS
uH : µ H
When indicating parts by reference num-
ber, please include the board.
SECTION 6
ELECTRICAL PARTS LIST
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
A-3021-289-A MAIN BOARD, COMPLETE (FX195:E,E9,CH)
A-3021-290-A MAIN BOARD, COMPLETE (FX193:E,E9,CH)
A-3021-291-A MAIN BOARD, COMPLETE (FX193:EA)
A-3021-292-A MAIN BOARD, COMPLETE (FX193:E5,E6)
A-3021-293-A MAIN BOARD, COMPLETE (FX193:US,CND)
A-3021-294-A MAIN BOARD, COMPLETE (FX193:AEP,CEV)
A-3021-295-A MAIN BOARD, COMPLETE (FX193:FR)
A-3021-296-A MAIN BOARD, COMPLETE (FX193:Italian)
A-3021-297-A MAIN BOARD, COMPLETE (FX195:EA)
A-3021-298-A MAIN BOARD, COMPLETE (FX195:CND)
A-3021-299-A MAIN BOARD, COMPLETE (FX195:AEP,CEV)
A-3021-300-A MAIN BOARD, COMPLETE (FX195:FR)
A-3021-301-A MAIN BOARD, COMPLETE (FX195:Italian)
A-3021-302-A MAIN BOARD, COMPLETE (FX195:E5,E6)
*********************************
3-029-332-02 TERMINAL (-), BATTERY
< CAPACITOR >
C1 1-163-083-00 CERAMIC CHIP 1PF 50V
(EXCEPT Italian,EA)
C1 1-163-085-00 CERAMIC CHIP 2PF 50V
(Italian,EA)
C2 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
(EXCEPT Italian,EA)
C2 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
(Italian,EA)
C3 1-163-093-00 CERAMIC CHIP 10PF 5% 50V
(EXCEPT Italian,EA)
C3 1-163-101-00 CERAMIC CHIP 22PF 5% 50V
(Italian,EA)
C4 1-163-575-11 CERAMIC CHIP 3PF 50V
(EXCEPT Italian,EA)
C4 1-163-088-00 CERAMIC CHIP 5PF 50V
(Italian,EA)
C4 1-163-089-00 CERAMIC CHIP 6PF 50V
C5 1-162-937-11 CERAMIC CHIP 6PF 0.5PF 50V
C6 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C7 1-165-128-11 CERAMIC CHIP 0.22uF 0% 16V
C8 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C9 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C10 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C11 1-107-823-11 CERAMIC CHIP 0.47uF 10% 16V
C12 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C13 1-163-091-00 CERAMIC CHIP 8PF 0.25PF 50V
(EXCEPT Italian,EA)
C13 1-163-217-11 CERAMIC CHIP 1PF 0.25PF 50V
(Italian,EA)
C14 1-135-151-21 TANTALUM CHIP 4.7uF 20% 4V
C15 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C16 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C17 1-124-584-00 ELECT 100uF 20% 10V
C18 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(US,CND,E5,E6)
C18 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(EXCEPT US,CND,E5,E6)
C19 1-163-023-00 CERAMIC CHIP 0.015uF 5% 50V
(US,CND,E5,E6)
C19 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
(EXCEPT US,CND,E5,E6)
C20 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C21 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C22 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C23 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C24 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C26 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C28 1-163-090-00 CERAMIC CHIP 7PF 50V
(EXCEPT Italian,EA)
C28 1-163-217-11 CERAMIC CHIP 1PF 50V
(Italian,EA)
C40 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C101 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C103 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C104 1-126-153-11 ELECT 22uF 20% 6.3V
C105 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C106 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C107 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C108 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C201 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C203 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C204 1-126-153-11 ELECT 22uF 20% 6.3V
C205 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C208 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C301 1-115-156-11 CERAMIC CHIP 1uF 0% 10V
C302 1-104-847-11 TANTAL. CHIP 22uF 20% 4V
C303 1-164-360-11 CERAMIC CHIP 0.1uF 16V
MAIN
• Abbreviation
CND : Canadian
EA : Saudi Arabia
CH : Chinese
E : Indication of country of origin
E9 : No Indication of country of origin
CEV : Ukraine, Hungary, Czech
E5, E6 : South America
FR : French

Sony WM-FX193 Specifications

General

Type	Cassette Player
Brand	Sony
Model	WM-FX193
Tuner	FM/AM
Power Source	2 x AA batteries
Mega Bass	Yes
Wow and Flutter	0.15%
Weight	190 g (without batteries)
