– 3 –
SECTION 2
DISASSEMBLY
Note : Follow the disassembly procedure in the numerical order given.
2-1. CABINET (REAR) SUB ASSY
2-2. MAIN BOARD
z
The equipment can be removed using the following procedure.
Main boardCabinet (rear) sub ASSY
Holder sub ASSY, Cassette
Mechanism deck Belt, Capstan/reel moter (M901)
Set
1
Screws B1.7x9
3
Claws
4
2
6
Claws
Holder sub ASSY, Cassette
Cabinet (front)
Cabinet (rear) sub ASSY
3
Claws
3
Claws
5
Claw
4
Claws
4
Claw
5
Claw
5
Claw
1
Screw WH1.4
3
Claws
2
Remove solder
4
Head flexible board
Red
White
Orange
Black
Cabinet (front)
Main board
