3-8. PINCH LEVER (N) / (R) ASSEMBLY
Claw
Claw
2
Remove the pinch lever
(N) assembly in the direction
of the arrow.
Note:
Be careful of the claw
1
Remove the pinch lever
(R) assembly in the direction
of the arrow.
Note:
Be careful of the claw
3-9. MAGNETIC HEAD (HP901)
1
Two screws
(M1.4
×
7.2)
2
Remove the magnetic head (HP901)
in the direction of the arrow.
