Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 31 —
SECTION 8
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they
may have some difference from the original
one.
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when
ordering these items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
A-3021-206-A MAIN BOARD, COMPLETE
********************
1-694-502-11 CONDUCTIVE BOARD, CONNECTION
3-034-073-01 HOLDER (LCD)
3-035-718-01 CUSHION (GR5)
< CAPACITOR >
C1 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C2 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C3 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C4 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C5 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C6 1-162-908-11 CERAMIC CHIP 3PF 0.25PF 50V
C7 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C8 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C9 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C10 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C11 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C12 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C13 1-107-817-11 TANTAL. CHIP 0.33uF 10% 16V
C14 1-162-905-11 CERAMIC CHIP 1PF 0.25PF 50V
C15 1-162-925-11 CERAMIC CHIP 68PF 5% 50V
C16 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C17 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C18 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C19 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C20 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C21 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C22 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C23 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C24 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C25 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C26 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C27 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C28 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C29 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C30 1-162-961-11 CERAMIC CHIP 330PF 10% 50V
C31 1-164-362-11 CERAMIC CHIP 470PF 5% 50V
C32 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C33 1-115-156-11 CERAMIC CHIP 1uF 10V
C34 1-115-156-11 CERAMIC CHIP 1uF 10V
C35 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
MAIN
C36 1-115-156-11 CERAMIC CHIP 1uF 10V
C37 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C38 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C39 1-115-412-11 CERAMIC CHIP 680PF 5% 25V
C40 1-127-578-11 TANTAL. CHIP 3.3uF 20% 6.3V
C41 1-110-563-11 CERAMIC CHIP 0.068uF 10% 16V
C42 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C43 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C44 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C45 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C46 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C47 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C48 1-115-156-11 CERAMIC CHIP 1uF 10V
C49 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C50 1-162-917-11 CERAMIC CHIP 15PF 5% 50V
C51 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C52 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C53 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C54 1-115-156-11 CERAMIC CHIP 1uF 10V
C55 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C56 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C57 1-162-910-11 CERAMIC CHIP 5PF 0.25PF 50V
C58 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C59 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C60 1-164-676-11 CERAMIC CHIP 2200PF 5% 16V
C61 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C62 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C63 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C64 1-164-217-11 CERAMIC CHIP 150PF 5% 50V
C65 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C66 1-164-245-11 CERAMIC CHIP 0.015uF 10% 25V
C101 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C104 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C105 1-115-156-11 CERAMIC CHIP 1uF 10V
C106 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C107 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C108 1-115-156-11 CERAMIC CHIP 1uF 10V
C110 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C111 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C201 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C204 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C206 1-115-156-11 CERAMIC CHIP 1uF 10V
C207 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C208 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
