Page #24 background imageLoading...
Page #24 background image
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 32 —
MAIN
C210 1-164-677-11 CERAMIC CHIP 0.033uF 10% 16V
C211 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C301 1-119-663-11 TANTAL. CHIP 47uF 20% 2.5V
C302 1-107-815-11 TANTAL. CHIP 2.2uF 20% 4V
C303 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C304 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C305 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C306 1-113-619-11 CERAMIC CHIP 0.47uF 10% 6.3V
C307 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C308 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C309 1-135-149-11 TANTALUM CHIP 2.2uF 20% 10V
C310 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C311 1-165-112-11 CERAMIC CHIP 0.33uF 16V
C312 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C313 1-115-156-11 CERAMIC CHIP 1uF 10V
C314 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C315 1-115-156-11 CERAMIC CHIP 1uF 10V
C316 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C317 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C318 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C319 1-162-969-11 CERAMIC CHIP 0.0068uF 10% 25V
C320 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C321 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C322 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C323 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C325 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C501 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C502 1-164-690-11 CERAMIC CHIP 0.0022uF 5% 50V
C503 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C504 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C505 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C506 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C507 1-162-967-11 CERAMIC CHIP 0.0033uF 10% 50V
C508 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C509 1-135-337-11 TANTAL. CHIP 1uF 20% 6.3V
C510 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C511 1-135-337-11 TANTAL. CHIP 1uF 20% 6.3V
C512 1-135-149-11 TANTALUM CHIP 2.2uF 20% 10V
C513 1-119-663-11 TANTAL. CHIP 47uF 20% 2.5V
C514 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C515 1-115-156-11 CERAMIC CHIP 1uF 10V
C516 1-115-156-11 CERAMIC CHIP 1uF 10V
C517 1-115-156-11 CERAMIC CHIP 1uF 10V
C518 1-115-156-11 CERAMIC CHIP 1uF 10V
C519 1-135-337-11 TANTAL. CHIP 1uF 20% 6.3V
C520 1-165-128-11 CERAMIC CHIP 0.22uF 16V
C521 1-115-156-11 CERAMIC CHIP 1uF 10V
C522 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C523 1-115-156-11 CERAMIC CHIP 1uF 10V
C524 1-115-156-11 CERAMIC CHIP 1uF 10V
C525 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C526 1-115-156-11 CERAMIC CHIP 1uF 10V
C527 1-115-156-11 CERAMIC CHIP 1uF 10V
C528 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C529 1-117-181-11 TANTAL. CHIP 4.7uF 20% 2.5V
C530 1-115-156-11 CERAMIC CHIP 1uF 10V
C531 1-115-156-11 CERAMIC CHIP 1uF 10V
C532 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C533 1-162-957-11 CERAMIC CHIP 220PF 5% 50V
C534 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C536 1-115-156-11 CERAMIC CHIP 1uF 10V
C537 1-115-156-11 CERAMIC CHIP 1uF 10V
C538 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C539 1-164-315-11 CERAMIC CHIP 470PF 5% 50V
C540 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C541 1-115-416-11 CERAMIC CHIP 1000PF 5% 25V
C542 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C601 1-125-837-11 CERAMIC CHIP 1uF 10% 6.3V
C602 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C603 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C604 1-164-360-11 CERAMIC CHIP 0.1uF 16V
C605 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C606 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C607 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C608 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C803 1-135-177-11 TANTALUM CHIP 1uF 20% 20V
C804 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C805 1-125-837-11 CERAMIC CHIP 1uF 6.3V
C806 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C807 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C808 1-115-156-11 CERAMIC CHIP 1uF 10V
C809 1-127-808-11 TANTAL. CHIP 10uF 20% 6.3V
C810 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C811 1-115-156-11 CERAMIC CHIP 1uF 10V
C812 1-125-984-11 TANTAL. CHIP 22uF 20% 4V
C813 1-115-156-11 CERAMIC CHIP 1uF 10V
< COMPOSITION CIRCUIT BLOCK >
CB301 1-127-678-21 CERAMIC CHIP 330PF 0 50V
< CERAMIC FILTER >
CF1 1-767-362-11 FILTER, CERAMIC (FM)(10.7MHz)
CF2 1-767-480-11 FILTER, CERAMIC (AM)(455KHz)
< CONNNECTOR >
CN501 1-766-339-21 CONNECTOR, FFC/FPC 9P
< DIODE >
D1 8-719-053-30 DIODE MA357(E)-(TX).SO
D2 8-719-053-30 DIODE MA357(E)-(TX).SO
D3 8-719-072-58 DIODE SVC347-TL
D4 8-719-404-50 DIODE MA111-TX
D5 8-719-049-09 DIODE 1SS367-T3SONY
D101 8-719-422-37 DIODE MA8051-TX
D201 8-719-422-37 DIODE MA8051-TX
D301 8-719-422-37 DIODE MA8051-TX
D302 8-719-422-37 DIODE MA8051-TX
D303 8-719-422-37 DIODE MA8051-TX
D801 8-719-049-09 DIODE 1SS367-T3SONY
D802 8-719-420-87 DIODE MA8130-TX
D803 8-719-404-50 DIODE MA111-TX
D804 8-719-420-51 DIODE MA729-TX
< FUSE >
F1 1-533-792-11 FUSE (SMD)(0.25A/125A)
