3-4. REEL ORNAMENT ASSEMBLY
1
Reel Ornament assembly
Remove the assembly while removin
the three claws and boss carefully.
Note:
Claw
Claw
3-5. MAIN BOARD
SLIDER
8
Remove soldeing
(two points)
from plunger solenoid.
6
Screw (B1.7
×
3)
tapping
5
Screw (B1.7
×
3)
tapping
3
Screw (1.4
×
1.6)
2
Screw (M1.4)
7
Screw (M1.4)
Toothed lock
1
Head flexible board
4
Screw (M1.4)
9
Remove soldeing
(four points) from
motor.
When assembling the MAIN board,
align the slider with the position of S1.
