Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
ā 35 ā
MAIN
R504 1-216-789-11 METAL CHIP 2.2 5% 1/16W
R505 1-216-835-11 METAL CHIP 15K 5% 1/16W
R506 1-216-835-11 METAL CHIP 15K 5% 1/16W
R507 1-216-827-11 METAL CHIP 3.3K 5% 1/16W
R508 1-216-835-11 METAL CHIP 15K 5% 1/16W
R509 1-216-863-11 RES, CHIP 3.3M 5% 1/16W
R510 1-216-833-11 RES, CHIP 10K 5% 1/16W
R511 1-216-833-11 RES, CHIP 10K 5% 1/16W
R512 1-216-833-11 RES, CHIP 10K 5% 1/16W
R513 1-216-833-11 RES, CHIP 10K 5% 1/16W
R514 1-216-863-11 RES, CHIP 3.3M 5% 1/16W
R517 1-216-817-11 METAL CHIP 470 5% 1/16W
R518 1-216-817-11 METAL CHIP 470 5% 1/16W
R520 1-216-817-11 METAL CHIP 470 5% 1/16W
R521 1-216-859-11 RES, CHIP 1.5M 5% 1/16W
R522 1-216-837-11 METAL CHIP 22K 5% 1/16W
R523 1-216-837-11 METAL CHIP 22K 5% 1/16W
R524 1-216-817-11 METAL CHIP 470 5% 1/16W
R525 1-216-817-11 METAL CHIP 470 5% 1/16W
R526 1-216-845-11 METAL CHIP 100K 5% 1/16W
R527 1-216-845-11 METAL CHIP 100K 5% 1/16W
R601 1-216-837-11 METAL CHIP 22K 5% 1/16W
R602 1-216-809-11 METAL CHIP 100 5% 1/16W
R603 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R604 1-216-823-11 METAL CHIP 1.5K 5% 1/16W
R605 1-216-833-11 RES, CHIP 10K 5% 1/16W
R607 1-216-845-11 METAL CHIP 100K 5% 1/16W
R801 1-216-849-11 METAL CHIP 220K 5% 1/16W
R802 1-216-829-11 METAL CHIP 4.7K 5% 1/16W
R803 1-216-817-11 METAL CHIP 470 5% 1/16W
R804 1-216-805-11 METAL CHIP 47 5% 1/16W
R805 1-216-819-11 METAL CHIP 680 5% 1/16W
R806 1-216-819-11 METAL CHIP 680 5% 1/16W
R807 1-216-845-11 METAL CHIP 100K 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB1 1-233-811-21 RES, NETWORK 470K (3216)
RB601 1-233-873-21 RES, NETWORK (CHIP TYPE)(3216)
< VARIABLE RESISTOR >
RV1 1-223-587-11 RES, ADJ, CARBON 22K
RV301 1-225-684-21 RES, VAR, CARBON 30K/30K (VOLā)
RV601 1-223-584-11 RES, ADJ, CARBON 2.2K
< SWITCH >
S1 1-771-475-21 SWITCH, SLIDE (REV-STOP-FWD)
S2 1-572-922-11 SWITCH, SLIDE (HOLD)
S3 1-771-053-21 SWITCH, KEY BOARD (p/RADIO OFF)
S4 1-771-053-21 SWITCH, KEY BOARD (FF/AMS)
S5 1-771-053-21 SWITCH, KEY BOARD (REW/AMS)
S6 1-771-053-21 SWITCH, KEY BOARD (MENU)
S7 1-771-053-21 SWITCH, KEY BOARD (SET)
S8 1-771-053-21 SWITCH, KEY BOARD (BAND)
S9 1-771-053-21 SWITCH, KEY BOARD (9(/REPEAT)
S10 1-771-053-21 SWITCH, KEY BOARD (ENTER)
S11 1-572-467-21 SWITCH, PUSH (1 KEY)(REC)
S501 1-692-605-51 SWITCH, SLIDE (ISS 1-2-3)
< TRANSFORMER >
T1 1-416-943-21 COIL (AM OSC)
T2 1-416-942-21 COIL (AM MIX)
T501 1-429-374-11 TRANSFORMER, BIAS OSCILLATION
T801 1-423-745-11 TRANSFORMER, DC-DC CONVERTER
< POSITIVE THERMISTER >
THP601 1-810-794-11 THERMISTOR, POSITIVE
< VIBRATOR >
X1 1-767-357-11 FILTER, CERAMIC (10.7MHz)
X2 1-579-615-11 VIBRATOR, CRYSTAL (75kHz)
************************************************************
MISCELLANEOUS
**************
17 1-672-579-11 FLEXIBLE (ATS) BOARD
S901 1-692-101-11 SWITCH, LEAF (TAPE/R TUME)
S902 1-692-100-11 SWITCH, LEAF (ATS/F TUME)
HP901 1-500-355-21 HEAD, MAGNETIC (REC/PB/ERASE)
M601 1-763-166-11 MOTOR (CAPSTAN/REEL)(WITH PULLEY)
PM901 1-454-674-31 SOLENOID, PLUNGER
************************************************************
ACCSSESORIES & PACKING MATERIALS
********************************
1-418-022-11 REMOTE CONTROL UNIT
1-528-543-22 BATTERY, NI-CD (NC-6WM)
! 1-528-580-21 BATTERY CHARGER (BC-7HT)
1-542-116-11 MICROPHONE
! 1-569-007-11 ADAPTOR, CONVERSION 2P
1-759-213-11 CASE, BATTERY
3-008-521-21 CASE, BATTERY CHARGE
3-029-488-01 POUCH, CARRYING
3-864-893-01 MANUAL, INSTRUCTION(JAPANESE/ENGLISH/
KOREAN/SIMPLIFIDE CHINESE)
8-953-304-90 RECEIVER MDR-E805SP SET
The components identified by mark ! or dotted
line with mark ! are critical for safety.
Replace only with part number specified.
