Sony XP-EV500 - 7 Electrical Parts List

26
XP-EV500/EV500C/EV500N/EV501R
SECTION 7
ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
f ied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
AUS:Australian model
CND : Canadian model
E18 : 100 – 240 V AC area in E model
E33 : 100 – 240 V AC area in E model
HK : Hong Kong model
MX : Mexican model
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
MAIN
Ver 1.2 2003.08
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
* A-3683-306-A MAIN BOARD, COMPLETE (EV500:AEP, UK)
*********************
* A-3683-556-A MAIN BOARD, COMPLETE (EV501R)
*********************
* A-3347-855-A MAIN BOARD, COMPLETE (EV500N:AEP)
*********************
* A-3663-994-A MAIN BOARD, COMPLETE
(EV500C/EV500N:CND, E)
*********************
* A-3347-900-A MAIN BOARD, COMPLETE
(EV500:E18, E33, HK, MX, AUS)
*********************
3-249-064-01 TERMINAL BOARD (+), BATTERY
3-249-065-01 TERMINAL BOARD (-), BATTERY
< CAPACITOR >
C205 1-115-156-11 CERAMIC CHIP 1uF 10V
C206 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C207 1-115-156-11 CERAMIC CHIP 1uF 10V
C208 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C210 1-115-156-11 CERAMIC CHIP 1uF 10V
C211 1-115-156-11 CERAMIC CHIP 1uF 10V
C212 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C214 1-115-156-11 CERAMIC CHIP 1uF 10V
C215 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C216 1-164-227-11 CERAMIC CHIP 0.022uF 10% 25V
C217 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C218 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C219 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C220 1-126-369-11 ELECT 220uF 20% 6.3V
C221 1-126-369-11 ELECT 220uF 20% 6.3V
C222 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C223 1-115-156-11 CERAMIC CHIP 1uF 10V
C224 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C225 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C226 1-115-156-11 CERAMIC CHIP 1uF 10V
C227 1-128-964-91 TANTAL. CHIP 100uF 20% 6.3V
C228 1-124-434-00 ELECT 220uF 20.00% 4V
C229 1-128-829-91 TANTAL. CHIP 220uF 20% 6.3V
C230 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C231 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C233 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C234 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C235 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C237 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C238 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C239 1-165-176-11 CERAMIC CHIP 0.047uF 10.00% 16V
C240 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C301 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C302 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C303 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C304 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C306 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C310 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C311 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C312 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C313 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C314 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C315 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C316 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C317 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C319 1-115-467-11 CERAMIC CHIP 0.22uF 10.00% 10V
C320 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C321 1-162-974-11 CERAMIC CHIP 0.01uF 50V
C322 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C402 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C403 1-117-720-11 CERAMIC CHIP 4.7uF 10V
C404 1-162-923-11 CERAMIC CHIP 47PF 5% 50V
C406 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C407 1-107-826-11 CERAMIC CHIP 0.1uF 10.00% 16V
C408 1-162-968-11 CERAMIC CHIP 0.0047uF 10% 50V
C409 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C410 1-125-891-11 CERAMIC CHIP 0.47uF 10.00% 10V
C411 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C412 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C413 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C414 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C415 1-117-863-11 CERAMIC CHIP 0.47uF 10.00% 6.3V
C416 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C417 1-162-919-11 CERAMIC CHIP 22PF 5% 50V
C418 1-107-811-11 TANTAL. CHIP 47uF 20% 4V
C419 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C420 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C421 1-164-315-11 CERAMIC CHIP 470PF 5.00% 50V
C422 1-110-569-11 TANTAL. CHIP 47uF 20.00% 6.3V
C423 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C424 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C425 1-131-862-91 TANTAL. CHIP 47uF 20% 4V
C428 1-127-569-91 TANTAL. CHIP 100uF 20% 4V
(EV500:AEP, UK/EV500C/EV500N/EV501R)
C429 1-115-156-11 CERAMIC CHIP 1uF 10V
C430 1-164-156-11 CERAMIC CHIP 0.1uF 25V
