Sony XP-EV500 - 2 General

4
XP-EV500/EV500N/EV501R
SECTION 2
GENERAL
This section is extracted
from instruction manual.
CD player (front)
CD player (rear/inside)
Remote control (XP-EV501R only)
Display
*The button has a tactile dot.
A
B
2SOUND
\ (headphones)
jack
6HOLD
DC IN 4.5 V
(external power
input) jack
7VOL +*/–
5s(stop)/OFF
/
CHARGE
Display
1P-MODE/
Strap holes
4ca *(play/
pause)/ENTER
3r/t
(skip/search)
OPEN
8E•A•S•S
Insert the ( end first (for both
batteries).
Open the battery
compartment lid.
Play mode
Track number Playing time
Remaining battery power
Sound mode
CHG
4ca
7VOL
Headphones
jack
3tF SKIP
3rB SKIP
2SOUND
6HOLD
5s
