Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
29
XP-EV500/EV500C/EV500N/EV501R
MAIN
< SWITCH >
S301 1-771-248-11 SWITCH, TACTILE (+)
S302 1-771-248-11 SWITCH, TACTILE (-)
S303 1-762-805-41 SWITCH, PUSH (1 KEY)
S304 1-771-586-11 SWITCH, SLIDE (HOLD .)
S305 1-771-586-11 SWITCH, SLIDE (E•A•S•S)
< VARISTOR >
VDR201 1-801-862-11 VARISTOR, CHIP (1608)
VDR202 1-801-862-11 VARISTOR, CHIP (1608)
VDR701 1-801-862-11 VARISTOR, CHIP (1608)
VDR702 1-801-862-11 VARISTOR, CHIP (1608)
VDR703 1-801-862-11 VARISTOR, CHIP (1608)
VDR704 1-801-862-11 VARISTOR, CHIP (1608)
< VIBRATOR >
X401 1-795-561-21 VIBRATOR, CERAMIC 16.934 MHz
************************************************************
MISCELLANEOUS
**************
13 1-805-122-11 DISPLAY PANEL, LIQUID CRYSTAL
14 1-477-704-11 SWITCH UNIT
0 102 X-3380-950-1 OPTICAL PICK-UP (DAX-25E)
M901 A-3180-965-A MOTOR ASSY, TURN TABLE (SPINDLE)
M902 A-3180-966-A MOTOR ASSY, SLED (SLED)
************************************************************
ACCESSORIES
************
1-417-362-11 CONNECTING PACK, CAR (CPA-7A) (EV500C)
0 1-477-496-21 ADAPTOR, AC (AC-ES455K) (EV500C:E33)
0 1-477-500-21 ADAPTOR, AC (AC-ES455K)
(EV500:AEP, E18, E33)
0 1-477-501-21 ADAPTOR, AC (AC-ES455K) (EV500:UK, HK)
0 1-477-502-21 ADAPTOR, AC (AC-ES455K)
(EV500:MX/EV500C:MX)
0 1-477-503-21 ADAPTOR, AC (AC-ES455K) (EV500:AUS)
1-477-746-11 REMOTE COMMANDER (RC-V845) (EV501R)
1-542-514-11 HEADPHONE (HP-M070)
(EV500/EV500C/EV500N:EXCEPT CND)
1-542-516-12 HEADPHONE (HP-M061) (EV500N:CND)
1-542-524-11 HEADPHONE (HP-M046) (EV501R)
0 1-569-007-12 ADAPTOR, CONVERSION 2P (E33)
3-252-374-21 MANUAL, INSTRUCTION (C) DHC-7C
(ENGLISH) (EV500N:CND/EV501R)
3-252-375-01 TAPE, MAGIC (EV500C)
3-252-446-11 MANUAL, INSTRUCTION (A) DHC-7L
(ENGLISH, FRENCH) (EV500C/EV500N:AEP)
3-252-446-12 MANUAL, INSTRUCTION (A) DHC-7L (CAR KIT)
(EV500C)
3-252-446-21 MANUAL, INSTRUCTION (A) DHC-7L
(GERMAN, ITALIAN) (EV500N:AEP)
3-252-446-31 MANUAL, INSTRUCTION (A) DHC-7L
(SPANISH, PORTUGUESE) (EV500C/EV500N:AEP)
3-252-446-41 MANUAL, INSTRUCTION (A) DHC-7L
(POLISH, HUNGARIAN) (EV500N:AEP)
3-252-446-51 MANUAL, INSTRUCTION (A) DHC-7L
(CZECH, RUSSIAN) (EV500N:AEP)
3-252-447-11 MANUAL, INSTRUCTION (B) DHC-7L
(ENGLISH, CHINESE) (EV500N:E)
3-252-476-11 MANUAL, INSTRUCTION (A) DHC-7
(ENGLISH, FRENCH) (EV500:AEP, UK, E33, MX, AUS)
3-252-476-21 MANUAL, INSTRUCTION (A) DHC-7
(GERMAN, ITALIAN) (EV500:AEP)
3-252-476-31 MANUAL, INSTRUCTION (A) DHC-7
(SPANISH, PORTUGUESE) (EV500:AEP, E33, MX)
3-252-476-41 MANUAL, INSTRUCTION (A) DHC-7
(POLISH, HUNGARIAN) (EV500:AEP)
3-252-476-51 MANUAL, INSTRUCTION (A) DHC-7
(CZECH, RUSSIAN) (EV500:AEP)
3-252-496-11 MANUAL, INSTRUCTION (B) DHC-7
(ENGLISH, TRADITIONAL CHINESE) (EV500:HK)
3-252-496-21 MANUAL, INSTRUCTION (B) DHC-7
(ENGLISH, SIMPLIFIED CHINESE) (EV500:E18)
Ver 1.2 2003.08
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
