Sony XR-1800R Service Manual

– 40 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
S950 1-771-484-11 SWITCH, TACTILE (OFF)
S951 1-771-484-11 SWITCH, TACTILE (PTY, LOUD)
S952 1-771-484-11 SWITCH, TACTILE (6)
S953 1-771-484-11 SWITCH, TACTILE (5)
S954 1-771-484-11 SWITCH, TACTILE (3)
S955 1-771-484-11 SWITCH, TACTILE (2)
S956 1-771-484-11 SWITCH, TACTILE (4)
S957 1-771-484-11 SWITCH, TACTILE (1, ATA)
************************************************************
* A-3317-253-A MAIN BOARD, COMPLETE (AEP, UK, SE)
* A-3317-255-A MAIN BOARD, COMPLETE (G)
*********************
* 3-022-470-01 BRACKET (IC)
* 3-022-477-01 HEAT SINK
7-685-793-09 SCREW +PTT 2.6X8 (S)
< CAPACITOR >
C1 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C2 1-124-584-00 ELECT 100uF 20% 10V
C3 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C4 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C5 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C6 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C7 1-126-623-11 CERAMIC CHIP 0.1uF 10% 25V
C8 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C9 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C10 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C12 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C13 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C50 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C51 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C52 1-125-701-11 DOUBLE LAYER 0.047F 5.5V
C53 1-124-584-00 ELECT 100uF 20% 10V
C62 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C100 1-163-235-11 CERAMIC CHIP 22PF 5% 50V
C101 1-126-565-11 ELECT 22uF 20% 16V
C102 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C103 1-126-565-11 ELECT 22uF 20% 16V
C104 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C105 1-126-565-11 ELECT 22uF 20% 16V
C106 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C107 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C108 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C116 1-163-205-00 CERAMIC CHIP 0.001uF 5% 50V
C117 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C118 1-126-565-11 ELECT 22uF 20% 16V
C120 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C121 1-164-161-11 CERAMIC CHIP 0.0022uF 10% 100V
C122 1-136-159-00 FILM 0.033uF 5% 50V
C123 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C124 1-163-017-00 CERAMIC CHIP 0.0047uF 5% 50V
C125 1-126-565-11 ELECT 22uF 20% 16V
C126 1-163-038-00 CERAMIC CHIP 0.1uF 25V
C127 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C128 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C129 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C130 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C131 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C132 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C133 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C135 1-137-194-11 FILM 0.47uF 5% 50V
C136 1-136-165-00 FILM 0.1uF 5% 50V
C150 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C151 1-126-157-11 ELECT 10uF 20% 16V
C152 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C153 1-163-237-11 CERAMIC CHIP 27PF 5% 50V
C154 1-163-239-11 CERAMIC CHIP 33PF 5% 50V
C155 1-163-133-00 CERAMIC CHIP 470PF 5% 50V
C157 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C158 1-164-004-11 CERAMIC CHIP 0.1uF 10% 25V
C200 1-164-345-11 CERAMIC CHIP 0.082uF 10% 25V
C201 1-163-024-00 CERAMIC CHIP 0.018uF 10% 50V
C202 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C250 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C251 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C252 1-124-254-00 ELECT 0.68uF 20% 50V
C253 1-124-254-00 ELECT 0.68uF 20% 50V
C254 1-110-501-11 CERAMIC CHIP 0.33uF 10% 16V
C255 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C350 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C351 1-163-275-11 CERAMIC CHIP 0.001uF 5% 50V
C352 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C353 1-126-565-11 ELECT 22uF 20% 16V
C354 1-126-154-11 ELECT 47uF 20% 6.3V
C355 1-126-154-11 ELECT 47uF 20% 6.3V
C356 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C357 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
C358 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C359 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C360 1-124-584-00 ELECT 100uF 20% 10V
C362 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C450 1-124-584-00 ELECT 100uF 20% 10V
C451 1-104-760-11 CERAMIC CHIP 0.047uF 10% 50V
C452 1-126-301-11 ELECT 1uF 20% 50V
C453 1-126-301-11 ELECT 1uF 20% 50V
C454 1-126-301-11 ELECT 1uF 20% 50V
C455 1-126-301-11 ELECT 1uF 20% 50V
C456 1-126-301-11 ELECT 1uF 20% 50V
C457 1-126-301-11 ELECT 1uF 20% 50V
C458 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C459 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C462 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C463 1-164-182-11 CERAMIC CHIP 0.0033uF 10% 50V
C464 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C465 1-163-037-11 CERAMIC CHIP 0.022uF 10% 25V
C466 1-164-157-11 CERAMIC CHIP 0.068uF 10% 25V
C467 1-164-157-11 CERAMIC CHIP 0.068uF 10% 25V
C468 1-126-157-11 ELECT 10uF 20% 16V
C469 1-126-157-11 ELECT 10uF 20% 16V
C470 1-126-565-11 ELECT 22uF 20% 16V
C471 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C500 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C501 1-164-505-11 CERAMIC CHIP 2.2uF 16V
C506 1-126-157-11 ELECT 10uF 20% 16V
KEY MAIN
