Sony XR-1800R Service Manual

– 41 –
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
C550 1-126-301-11 ELECT 1uF 20% 50V
C551 1-126-301-11 ELECT 1uF 20% 50V
C552 1-126-301-11 ELECT 1uF 20% 50V
C553 1-126-301-11 ELECT 1uF 20% 50V
C554 1-124-589-11 ELECT 47uF 20% 16V
C556 1-163-243-11 CERAMIC CHIP 47PF 5% 50V
C557 1-124-257-00 ELECT 2.2uF 20% 50V
C571 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C572 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C573 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C574 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C600 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C601 1-163-117-00 CERAMIC CHIP 100PF 5% 50V
C602 1-126-937-11 ELECT 4700uF 20% 16V
C603 1-163-077-00 CERAMIC CHIP 0.1uF 10% 25V
C604 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C605 1-163-181-00 CERAMIC CHIP 100PF 5% 50V
C607 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C608 1-124-589-11 ELECT 47uF 20% 16V
C609 1-126-565-11 ELECT 22uF 20% 16V
C610 1-163-021-11 CERAMIC CHIP 0.01uF 10% 50V
C613 1-164-489-11 CERAMIC CHIP 0.22uF 10% 16V
C620 1-126-157-11 ELECT 10uF 20% 16V
C621 1-136-165-00 FILM 0.1uF 5% 50V
C622 1-163-009-11 CERAMIC CHIP 0.001uF 10% 50V
C623 1-163-251-11 CERAMIC CHIP 100PF 5% 50V
< CONNECTOR >
CN900 1-764-808-21 JACK (ANT) (FM/AM ANTENNA)
CN901 1-573-489-11 PIN, CONNECTOR (PC BOARD) 11P
CN902 1-764-423-11 PIN, CONNECTOR 12P
CN903 1-774-701-11 PIN, CONNECTOR 16P
< DIODE >
D50 8-719-914-44 DIODE DAP202K
D51 8-719-988-62 DIODE 1SS355
D52 8-719-991-33 DIODE 1SS133T-77
D53 8-719-991-33 DIODE 1SS133T-77
D61 8-719-109-93 DIODE RD6.2ESB2
D62 8-719-109-93 DIODE RD6.2ESB2
D63 8-719-109-93 DIODE RD6.2ESB2
D64 8-719-109-93 DIODE RD6.2ESB2
D65 8-719-105-99 DIODE RD6.2M-B1
D66 8-719-105-99 DIODE RD6.2M-B1
D67 8-719-109-93 DIODE RD6.2ESB2
D100 8-719-977-03 DIODE DTZ5.6B
D350 8-719-200-82 DIODE 11ES2
D351 8-719-988-62 DIODE 1SS355
D501 8-719-200-82 DIODE 11ES2
D502 8-719-200-82 DIODE 11ES2
D550 8-719-991-33 DIODE 1SS133T-77
D600 8-719-110-53 DIODE RD20ES-B2
D601 8-719-110-53 DIODE RD20ES-B2
D602 8-719-049-38 DIODE 1N5404TU
D603 8-719-110-09 DIODE RD8.2ES-B3
D604 8-719-110-49 DIODE RD18ES-B2
D605 8-719-110-03 DIODE RD7.5ESB2
D606 8-719-110-14 DIODE RD9.1ES-B3
D607 8-719-933-43 DIODE HZS7AIL
D608 8-719-988-62 DIODE 1SS355
D609 8-719-200-82 DIODE 11ES2
D610 8-719-200-82 DIODE 11ES2
< DISCHARGE GAP >
DSP100 1-519-504-11 GAP, DISCHARGE
< IC >
IC1 8-759-549-48 IC MN1884820SF
IC50 8-759-363-81 IC XC61AN4002PR
IC120 8-759-242-66 IC TC4W66F
IC121 8-759-823-81 IC LC7216M
IC150 8-759-163-63 IC TDA7330BD-013TR
IC350 8-759-924-46 IC BA4560F
IC450 8-759-368-11 IC LC75372E
IC500 8-759-490-48 IC HA13158
< SHORT >
JC4 1-216-295-00 SHORT 0
JC5 1-216-296-00 SHORT 0
JC6 1-216-295-00 SHORT 0
JC7 1-216-295-00 SHORT 0
JC8 1-216-295-00 SHORT 0
JC9 1-216-295-00 SHORT 0
JC10 1-216-296-00 SHORT 0
JC12 1-216-296-00 SHORT 0
JC14 1-216-295-00 SHORT 0
JC15 1-216-296-00 SHORT 0
JC16 1-216-296-00 SHORT 0
JC17 1-216-295-00 SHORT 0
JC18 1-216-295-00 SHORT 0
JC20 1-216-295-00 SHORT 0
JC31 1-216-296-00 SHORT 0
JC32 1-216-296-00 SHORT 0
JC35 1-216-295-00 SHORT 0
JC36 1-216-296-00 SHORT 0
JC37 1-216-295-00 SHORT 0
JC38 1-216-295-00 SHORT 0
< COIL >
L1 1-410-509-11 INDUCTOR 10uH
L120 1-410-509-11 INDUCTOR 10uH
L150 1-410-513-11 INDUCTOR 22uH
L600 1-411-669-21 INDUCTOR 0uH
< TRANSISTOR >
Q50 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q51 8-729-027-23 TRANSISTOR DTA114EKA-T146
Q100 8-729-620-06 TRANSISTOR 2SC3052-EF
Q101 8-729-900-53 TRANSISTOR DTC114EK
Q102 8-729-901-98 TRANSISTOR 2SA1036K-R
Q103 8-729-900-53 TRANSISTOR DTC114EK
Q104 8-729-900-53 TRANSISTOR DTC114EK
Q105 8-729-901-98 TRANSISTOR 2SA1036K-R
Q106 8-729-106-68 TRANSISTOR 2SD1615A-GP
Q120 8-729-021-94 FET 2SK1657-T1B
MAIN
