3-4. EXPLODED VIEW AND PART LIST
SECTION 3: XR-77A8*K
REF.
NO
PART NO. DESCRIPTION
XR-77A80K
XR-
77A80CK
UCM LA8 UC2
1
5-039-876-01
LABEL, SIDE TERMINAL HP (TGR)
• n/a •
1 5-039-876-21
LABEL, SIDE TERMINAL HP (TGR)
n/a • n/a
2
5-033-671-01
BTM COVER BARE (COM SEP)
• • •
3
5-033-669-01
TERMINAL COVER (COM SEP)
• • •
4 5-036-379-01
REAR COVER (3L SEP) A
• • •
5 5-023-743-01
BRACKET, AC INLET (C18)
• • •
6 5-039-955-11
BRACKET SIDE (BNN) A
• n/a •
6 5-039-955-01
BRACKET SIDE (BNN) A
n/a • n/a
7
1-013-469-11
SP-BOX ASSY,FY22 W40L-A
• • •
8
1-013-469-21
SP-BOX ASSY,FY22 W40L-B
• • •
9
5-009-258-21
BRACKET, WIFI(BNN)
• • •
10
1-005-419-13
WLAN/BT MODULE(11AC)
• • •
11
A-5042-836-A COMPL_SVC_BM5STY_UC_FS_77
• n/a •
11
A-5042-839-A COMPL_SVC_BM5STY_LABR_FS_77
n/a • n/a
12
4-457-451-12
SHEET, THERMAL (BAF)
• • •
13
1-013-510-11
G26-STATIC CONVERTER (TV)
• • •
REF.
NO
PART NO. DESCRIPTION
XR-77A80K
XR-
77A80CK
UCM LA8 UC2
14 5-035-921-11
SHEET, INSULATION (3L SEP) A
• n/a •
14 5-035-588-11
SHEET, INSULATION (3L SEP)
n/a • n/a
15
A-5044-489-A P-MOD (YDCM077UNG13)(SVC)
• • n/a
16 5-034-385-01
STAND L (3L SEP) A
• • •
17 5-034-386-01
STAND R (3L SEP) A
• • •
Caution : When replacing the power supply board, please reuse the
BRACKET, AC INLET (C18).
SYSSET
2022/04/1221:41:16(GMT+09:00)
