Sony XR-55A80K - Page 61

SCREW
61
REMARKS P/N DESCRIPTION QTY TORQUE (N.m)
4-472-518-11 SCREW, +PSW M3X6 16 0.4 ± 0.05
7-682-948-09 SCREW, +PSW 3X8 2 0.4 ± 0.05
5-015-521-01 +PSW M6*16 W14 4
1.2 ± 0.1
TOOLS & EQUIPMENTS FFC PRECAUTIONS SECTION 1 SECTION 2 SECTION 3 SMART CORE APPENDIX
3-4. EXPLODED VIEW AND PART LIST
SECTION 3: XR-77A8*K
SYSSET
