The units in this manual contain a self-diagnostic function. If an error occurs, the Smart Core Red LED will automatically begin to flash. The number of times the LED flashes
translates to a probable source of the problem.
A definition of the Smart Core Red LED flash indicators is listed in the instruction manual for the users knowledge and reference.
If an error symptom cannot be reproduced, the remote commander can be used to review the failure occurrence data stored in memory to reveal past problems and how often
these problems occur.
DIAGNOSTIC TEST INDICATORS
When an error occurs, the Smart Core Red LED will flash a set number of times to indicate the possible cause of the problem. If there is more than one error, the LED
will identify the first of the problem areas.
Result for all of the following diagnostic items are displayed on screen. If the screen displays a “0”, no error has occurred .
Self Diag. Quick Reference (LED blinking)
SELF DIAGNOSIS FUNCTION
Smart Core RED LED
blinking count
Error Item Detection items 55” / 65”/ 77” Detection items 83”
2x MAIN_POWER <B/G> Main 12V over voltage
3x
DC_ALERT <B/G> Main 5.0V failure
AUD_ERR <B/S> Audio amp. protection
4x
LD_ERR
'LD_ERR’ for T-con internal error
<P/T/B/G>TCON internal error/TCON I2C communication
failure
BCM_ERR
'BCM_ERR’ for EVDD_ERR <P/T/G/B> EVDD failure
5x P_ID_ERR <B/T/P/G> Panel ID EEPROM I2C No ACK (Also panel power failure is a suspect)
<P/T/G/B> Panel ID EEPROM I2C No ACK
(Also, panel power failure is a suspect)
<T/B>Data corruption in EEPROM
6x BACKLIGHT_ERR <B/G/P/LD> Backlight failure <P/G/B> EVDD over voltage
7x TEMP_ERR <B/H/P> Over temperature protection
8x 4KBE_ERR <B> 4KBE WDT
Blue italic: detect at startup sequence only.
<G>: Power Supply board, <B>: Main board, <T>: T-con board, <LD>: LD board, <P>: Panel module, <S>: Speaker, <H>: H-board
SYSSET
2023/11/2806:39:49(GMT+09:00)
