Sony XR-77A80L User Manual

6
To reduce the risk of image retention:
• Fill the screen by changing [Wide mode] to eliminate the black bars.
Select [Wide mode] other than [Normal].
• Turn off the OSD (On Screen Display) by pressing the DISPLAY button and
turn off the menus from connected equipment. For details, refer to the
instruction manuals for the connected equipment.
• Avoid displaying static images with bright colours (including white), clocks
or logos on any portion of the screen.
• Set the picture settings based on the ambient conditions. The Standard
Picture is recommended for home use and when viewing content that often
displays the station logos, etc. The TV has following features to help reduce/
prevent image retention. Press the HOME button, then select [Settings] –
[Picture & Display] – [Expert panel settings] – the desired option.
Panel refresh
Panel refresh will automatically run to adjust the uniformity of the TV screen
after it has been in use for long periods.Panel refresh can also be performed
manually and should only be used if image retention is very noticeable, or you
see the following message: [Panel refresh did not finish...]
Caution:
• The Panel refresh function may affect the panel. As a reference, perform the
Panel refresh only once a year, do not perform it more than once a year as it
may affect the usable life of the panel.
• Panel refresh takes about one hour to complete.
• A white line may be displayed on the screen during the Panel refresh, this is
not a malfunction of the TV.
• Panel refresh will only work when the room temperature is between 10-40ºC.
Pixel shift.
Automatically moves the image on the screen to prevent image retention.
Another feature.
The screen brightness is automatically reduced when displaying still images,
clocks, bright colors or logos etc.
SAFETY NOTES
SYSSET
2023/11/2806:39:49(GMT+09:00)

Sony XR-77A80L Specifications

General

Sound modes	Cinema, Dialog, Dolby Audio, Music, Sports, Standard
Audio decoders	Dolby Atmos, DTS Digital Surround
RMS rated power	60 W
Number of speakers	5
Audio output channels	3.2 channels
Enhanced Audio Return Channel (eARC)	Yes
HDCP version	2.3
Headphone outputs	-
HDMI ports quantity	4
USB 2.0 ports quantity	2
Digital audio optical out	1
Consumer Electronics Control (CEC)	BRAVIA Sync
Color name	Titanium Black
Stand type	Legs stand
Stand color	Black
Panel mounting interface	300 x 300 mm
Screen shape	Flat
Response time	8 ms
Display diagonal	77 \
Display brightness	- cd/m²
Display technology	OLED
Native aspect ratio	16:9
Native refresh rate	120 Hz
Supported video modes	480p, 720p, 1080i, 1080p, 2160p
Display diagonal (metric)	195 cm
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160
AC input voltage	110-240 V
AC input frequency	60 Hz
Energy efficiency scale	A to G
Power consumption (standby)	0.5 W
Power consumption (typical)	142 W
Package depth	188 mm
Package width	1911 mm
Package height	1137 mm
Package weight	51000 g
Video apps	TV SideView
Smart modes	Cinema, Custom, Dolby Vision, Game, Graphics, IMAX Enhanced, Netflix Calibrated, Photo, Standard, True Cinema, Vivid
App distribution platform	Google Play
Operating system installed	Google TV
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Bluetooth profiles	A2DP, AVRCP, HID, HOGP, SPP
Game features	Auto Low Latency Mode (ALLM), Variable Refresh Rate (VRR)
USB recording	No
Audio formats supported	LPCM
Video formats supported	ASF, AVC, AVCHD, AVI, HEVC, M-JPEG, MPEG1, MPEG2-PS, MPEG2-TS, MPEG4, VC-1, WMV, XVID
Picture processing technology	Sony Cognitive Processor XR, Sony Dynamic Contrast Enhancer, Sony Live Colour, Sony XR HDR Remaster, Sony XR Smoothing, Sony XR Super Resolution
High Dynamic Range (HDR) technology	Dolby Vision, High Dynamic Range 10 (HDR10), Hybrid Log-Gamma (HLG)
Cables included	AC
Manual languages	ENG, ESP, FRE
On Screen Display (OSD) languages	AFR, ARA, BEL, BOS, BUL, CAT, CZE, DAN, DEU
Tuner type	Analog & digital
Number of tuners	1 tuner(s)
Supported TV bands	CATV, UHF, VHF
Analog signal format system	VHF
Digital signal format system	ATSC, QAM

Weight and Dimensions

Stand width	1409 mm
Depth (with stand)	389 mm
Height (with stand)	1066 mm
Weight (with stand)	37000 g
Depth (without stand)	54 mm
Width (without stand)	1722 mm
Height (without stand)	998 mm
Weight (without stand)	34800 g
