6SG 105(w)/115(w)/125(w)/135(w) Rev. 3
Operating Instructions
Expansion Modules
The SG 125(w)/135(w) support an additional expansion module allowing you to
insert an optional 3G/4G or Wireless module (on SG 135w only). These modules
are not delivered with the appliance but available through your Sophos partner.
Please note that there are different 3G/4G modules available depending on the
region you want to operate it in Americas/EMEA and APAC.
Please see table below for further details.
Target Region Americas/EMEA APAC
4G LTE
Category Cat-6 Cat-6
Frequency Bands B1, B2, B3, B4, B5, B7,
B12, B13, B20, B25,
B26, B29, B30, B41
B1, B3, B5, B7, B8, B18, B19,
B21, B28, B38, B39, B40, B41
3G
1. Technology supported WCDMA WCDMA
Frequency Bands B1, B2, B3, B4, B5, B8 B1, B5, B6, B8, B9, B19
2. Technology supported TD-SCDMA
Frequency Bands B39
DATA SPEED
Peak Downlaod Rate 300 Mbps 300 Mbps
Peak Upload Rate 50 Mbps 50 Mbps
LOCATION SERVICES
Satellite Systems GPS, Galileo, Glonass, Beidou GPS, Galileo, Glonass, Beidou
For installing the module please read the mounting instructions which are
shipped with each module.
Serial Console
You can connect a serial console to either of the COM ports of the Sophos SG
hardware appliances. You can use, for instance, the Hyperterminal terminal
program which is included with most versions of Microsoft Windows to log on to
the appliance console. Use an RJ45 to DB9 adapter cable or the provided USB
cable to connect the console to your hardware appliance.
The required connection settings are:
Ì Bits per second: 38,400
Ì Data bits: 8
Ì Parity: N (none)
Ì Stop bits: 1
Access via the serial console is activated by default on ttyS1. The connections of
the appliances and the respective functionality are listed in chapter “Operating
Elements and Connections.”
