3
Mount the appliance to the rack
Please follow the rack mounting instructions as described in the UTM Operating
Instructions.
*
3. Power Up the Device
Connect the power cable and turn on the device
Connect the device to the power supply using the power cable(s). Turn the device
on. The power switch is on the back of the device and is placed next to the power
connection. Once the device has booted completely, you’ll hear an acoustic signal:
five beeps in a row.
4. Configure the device
Use your browser to make the initial connection to the WebAdmin GUI
You will need to configure a workstation with the necessary LAN properties to access
WebAdmin. You can change these settings later to match your existing network. The
location of the menu for these settings depends on the operating system of your client.
Example: With Windows 7, the menu can be found under Start >> Control Panel >>
Network and Sharing Center
Start the browser and enter the management IP address of the appliance:
https://192.168.0.1:4444
Accept the security notice by clicking OK (Mozilla Firefox) or Yes (MS Internet Explorer).
For configuration you can follow the initial setup wizard described in the WebAdmin
Quick Start Guide
**
or cancel it and perform a manual setup (see the UTM
Administration Guide
*
).
Quick Start Guide SG 210 Rev. 3, SG 230 Rev. 2
Workstation connection properties:
IP address: Any address in the range 192.168.0.2
through 192.168.0.254
Netmask: Enter 255.255.255.0
Standard gateway: Enter the IP address of
the appliance’s internal network card E0/LAN:
192.168.0.1
DNS server: Enable this option and enter the IP
address of the internal network card E0/LAN:
192.168.0.1
* Available at www.sophos.com/en-us/support/documentation/sophos-utm
** Available via WebAdmin >> Support >> Manual
