4XGS 2100/2300/3100/3300
Operating Instructions
Interfaces (front)
LAN Ports Type Speed Comment
1–8 RJ45 10/100/1000 Mbps Ports 1/2 can be configured as a bypass pair.
F1–F2
(XGS 2100/2300 only)
SFP 1 Gbps
F1–F2
(XGS 3100/3300 only)
SFP+ 1/10 Gbps
F3–F4
(XGS 3100/3300 only)
SFP 1 Gbps
Other Ports Type Comment
COM RJ45/Micro USB You can connect a serial console to either the RJ45 or
micro USB COM port to access the CLI. Only one port
can be used at any time. If both ports are connected
then the micro USB port will take precedence.
The required connection settings are:
Ì Bits per second: 38,400
Ì Data bits: 8
Ì Parity: N (none)
Ì Stop bits: 1
USB USB 3.0 (Type A) You can connect a USB 2.0 or 3.0 compatible device to
this port (e.g. USB thumb drive, UPS, 3G/4G dongles).
MGMT RJ45 (10/100/1000 Mbps) We recommend using this dedicated
port to connect your Admin PC.
USB (rear) USB 2.0 (Type A) You can connect a USB 2.0 compatible
device to this port (e.g. keyboard).
Module Slots Type Comment
A Flexi Port Can be used for any Flexi Port module
listed in the table below
Compatible Modules
*
Comment
8 port GbE copper Flexi Port
8 port GbE SFP Flexi Port
4 port GbE copper – 2 Bypass groups Flexi Port
4 port 10 GbE SFP+ Flexi Port
2 port GbE fiber (LC) Bypass + 4 port GbE SFP Flexi Port
4 port 2.5 GbE copper PoE Flexi Port
4 port GbE copper PoE + 4 port GbE copper Flexi Port
* SFP/SFP+/QSFP transceivers are sold separately.
