Sophos XGS 3100 User Manual

5XGS 2100/2300/3100/3300
Operating Instructions
Technical Specifications
XGS 2100 XGS 2300 XGS 3100 XGS 3300
Physical Specification
#Fixed Ethernet
Ports
10 10 12 12
#Fixed ByPass
Port Pairs
1 1 1 1
max. #Flexi Ports 8 8 8 8
#Cores Main CPU 2/4 2/4 4/4 4/8
Main Memory 8 GB DDR4 2400 8 GB DDR4 2400 12 GB DDR4 2666 16 GB DDR4 2666
#Cores NPU 16 16 20 20
NPU Memory 4GB DDR4 4GB DDR4 4GB DDR4 4GB DDR4
Stoarge 1 x 120 GB 1 x 120 GB 1 x 240 GB 1 x 240 GB
Power Supply Internal auto-ranging
AC-DC 100–240VAC,
3–6A@50–60 Hz
External Redundant
PSU Option
Internal auto-ranging
AC-DC 100–240VAC,
3–6A@50–60 Hz
External Redundant
PSU Option
Internal auto-ranging
AC-DC 100–240VAC,
3–6A@50–60 Hz
External Redundant
PSU Option
Internal auto-ranging
AC-DC 100–240VAC,
3–6A@50–60 Hz
External Redundant
PSU Option
Power
Consumption (idle)
43 W/146.86 BTU/hr 45 W/153.7 BTU/hr 50 W/170.77 BTU/hr 50 W/170.77 BTU/hr
Power
Consumption
(full load)
162 W/533.5 BTU/hr 167 W/570.74
BTU/hr
182 W/621.97
BTU/hr
201 W/686.68
BTU/hr
PoE addition
enabled
76 W/260 BTU/hr 76 W/260 BTU/hr 76 W/260 BTU/hr 76 W/260 BTU/hr
Mounting Rackmount (1U
sliding rails option)
min. rack depth: 603
mm (23.74")
max. rack depth:
930 mm (36.61")
Rackmount (1U
sliding rails option)
min. rack depth: 603
mm (23.74”)
max. rack depth:
930 mm (36.61”)
Rackmount (1U
sliding rails option)
min. rack depth: 603
mm (23.74”)
max. rack depth:
930 mm (36.61”)
Rackmount (1U
sliding rails option)
min. rack depth: 603
mm (23.74”)
max. rack depth:
930 mm (36.61”)
Dimensions
Width x Depth
x Height
438 x 405 x 44 mm
17.24 x 15.94 x
1.73 inches
438 x 405 x 44 mm
17.24 x 15.94 x
1.73 inches
438 x 405 x 44 mm
17.24 x 15.94 x
1.73 inches
438 x 405 x 44 mm
17.24 x 15.94 x
1.73 inches
Weight (kg)
unpacked/packed
4.7 kg/10.36 lbs
(unpacked)
7 kg/15.43 lbs
(packed)
4.7 kg/10.36 lbs
(unpacked)
7 kg/15.43 lbs
(packed)
4.7 kg/10.36 lbs
(unpacked)
7 kg/15.43 lbs
(packed)
4.7 kg/10.36 lbs
(unpacked)
7 kg/15.43 lbs
(packed)
Environmental
Noise level (avg.)
typical idle/
typ. max
34.9/53.9 dBA 34.9/43.6 dBA 34.9/47.3 dBA 34.9/47.3 dBA
Operating
Temperature
0°C to 40°C 0°C to 40°C 0°C to 40°C 0°C to 40°C
Storage
Temperature
-20°C to 70°C -20°C to 70°C -20°C to 70°C -20°C to 70°C
Opertional/
Storage Humidity
10% to 90% non-
condensing
10% to 90% non-
condensing
10% to 90% non-
condensing
10% to 90% non-
condensing
Altitude 2000m 2000m 2000m 2000m
MTBF (hours)
(Telcordia SR-
332 Issue 3)
110,442 110,442 110,058 109,676
Certifications
(Safety, EMC)
CB, CE, UL, FCC, ISED,
VCCI, CCC, KC, BSMI,
RCM, NOM, Anatel
CB, CE, UL, FCC, ISED,
VCCI, CCC, KC, BSMI,
RCM, NOM, Anatel
CB, CE, UL, FCC, ISED,
VCCI, CCC, KC, BSMI,
RCM, NOM, Anatel
CB, CE, UL, FCC, ISED,
VCCI, CCC, KC, BSMI,
RCM, NOM, Anatel
