Registered Quality System to ISO 9001:2008
13/60
Form 912
sorinc.com
913-888-2630
1” Connection
1-1/2” Connection
2” Connection
Notes
1. Dimensions D and E apply to socket-weld connections only. Consult factory for NPT dimensions.
2. Consult factory for dimensions for materials other than carbon steel.
3. Applies to socket weld or NPT process connections only.
4. Consult the factory if weld neck process flanges are required. Dimensions may vary from those shown above.
5. Applies to flanged process connections only.
Chamber Dimensions
100 Series
Model
D
1, 2
E
1, 2
F
4
G H
4
I
2
L
2
inch mm inch mm inch mm inch mm inch mm inch mm inch mm
101
10-1/2 267 3-3/4 95 6-1/2 165 14 356 14 356 3-3/4 95
16-5/8 422
102 17-5/16 440
103
10-1/4 260 4-13/16 122 7-7/16 189 14 356 14 356 4-9/16 116
18 457
104 19-3/4 502
109 12-5/8 321 5-13/16 148 8-7/16 214 16 406 16 406 7-1/2 191 17-13/16 452
121
9 229 3-1/4 83 6 152 14 356 14 356 3-3/4 95
16-3/8 416
122 16-15/16 430
123
10-1/2 267 3-3/4 95 6-1/2 165 14 356 14 356 3-3/4 95
17-5/16 440
124 18-3/4 476
Model
D
1, 2
E
1, 2
F
4
G H
4
I
2
L
2
inch mm inch mm inch mm inch mm inch mm inch mm inch mm
101
10-1/2 267 4 102 6-1/2 165 14 356 14 356 3-3/4 95
16-5/8 422
102 17-5/16 440
103
10-1/4 260 5-1/16 129 7-7/16 189 14 356 14 356 4-9/16 116
18 457
104 19-3/4 502
109 13-1/16 332 6-1/16 154 8-7/16 214 16 406 16 406 7-1/2 191 17-13/16 452
121
9 229 3-1/2 89 6 152 14 356 14 356 3-3/4 95
16-3/8 416
122 16-15/16 430
123
10-1/2 267 4 102 6-1/2 165 14 356 14 356 3-3/4 95
17-5/16 440
124 18-3/4 476
Model
D
1, 2
E
1, 2
F
4
G H
4
I
2, 3
L
2, 3
inch mm inch mm inch mm inch mm inch mm inch mm inch mm
101
10-1/2 267 4-5/16 110 6-1/2 165 14 356 14 356 4-3/4 121
17-5/8 448
102 18-5/16 467
103
10-1/4 260 5-3/8 137 7-7/16 189 14 356 14 356 4-9/16 116
19 483
104 20-3/4 527
109 13-3/8 340 6-3/8 162 8-7/16 214 16 406 16 406 8-1/2 216 18-13/16 478
121
- - - - 6 152 14 356 14 356 3-3/4
5
95
5
16-3/8
5
416
5
122
16-15/16
5
430
5
123
10-1/2 267 4-5/16 110 6-1/2 165 14 356 14 356 4-3/4 121
18-5/16 465
124 19-3/4 502
