Registered Quality System to ISO 9001:2008
57/60
Form 912
sorinc.com
913-888-2630
Ring Tight Joint Flanges (RTJ)
The side surfaces of RTJ gasket surfaces shall not exceed 63µ” (1.6µm) roughness per ANSI B16.5.
The specific gravity of water changes depending on its temperature and pressure. The chart below
lists properties of saturated steam. Saturated steam is the state where water is in transition between
liquid and vapor. The chart provides the process temperature with the associated pressure and spe-
cific gravity of the condensate water. If a water application has a high temperature and low pressure,
condensate will only be present at the temperature that corresponds to the maximum pressure.
Select the proper row based on the temperature and pressure, and read the specific gravity.
Figures are based on saturated steam.
Specific Gravity of Water
Mechanical
Level Switches
Boiling
Temperature
F
°
Vacuum
Inches Hg
Specific
Gravity
32 29.74 .9999
40 29.67 1.0000
50 29.56 .9997
60 29.40 .9990
70 29.18 .9980
80 28.89 .9966
90 28.50 .9950
100 27. 9 9 .9931
110 27.33 .9909
120 26.48 .9886
130 25.40 .9860
140 24.04 .9832
150 22.35 .9803
160 20.27 .9772
170 17.72 .9730
180 14.63 .9704
190 10.91 .9668
200 6.46 .9631
210 1.17 .9592
Boiling
Temperature
F
°
Pressure
psig
Specific
Gravity
212 0.0 .96
220 2.49 .96
230 6.08 .95
240 10.27 .95
250 15.13 .94
260 20.14 .94
270 27. 17 .93
280 34.52 .93
290 42.87 .92
300 52.30 .92
310 63.00 .91
320 75.00 .91
330 89.3 .91
340 103.3 .90
350 119.9 .89
360 138.3 .88
370 158.5 .88
380 180.9 .87
390 205.4 .86
400 232.3 .86
410 261.6 .85
420 293.4 .84
430 328.4 .84
440 366.2 .83
Boiling
Temperature
F
°
Pressure
psig
Specific
Gravity
450 4 07. 0 .82
460 451.2 .81
470 498.8 .80
480 550.1 .80
490 605.2 .79
500 664.3 .78
510 728.3 .77
520 795.3 .76
530 868.3 .76
540 945.3 .74
550 1028.3 .73
560 1116.3 .71
570 1209.3 .70
580 1308.3 .69
590 1414.3 .68
600 1529.3 .67
610 1644.3 .66
620 1769.3 .65
630 1902.3 .63
640 2042.3 .62
650 2190.3 .60
660 2346.3 .58
670 2511.3 .56
680 2690 .49
690 2883 .48
700 3075 .44
705 3189 .32
