ASTM Material Designations
SOR uses all ASTM grade materials in the construction of mechanical level switches. The following chart
lists the specific ASTM (or UNS) materials that are normally used for each component in our switches.
Consult the factory if you do not see the specific material required for your application.
Notes
1. UNS numbers are given in parenthesis for special alloys.
2. These materials are available by special order only.
Ring Tight Joint Flanges (RTJ)
The side surfaces of RTJ gasket surfaces shall not exceed 63µ” (1.6µm) roughness per ANSI B16.5.
Mechanical
Level Switches
Raised Face Flanges (RF)
All raised-face flange finishes are given as a range. AARH (Average Arithmetic Root Height) values are
given with their metric equivalent.
Flange Face Finishes
The most common flange face finishes are shown. SOR standard flange finishes are
highlighted.
Material
ANSI B36.10 ANSI B16.9 ANSI B36.10 ANSI B16.5
Temperature
Range
Seamless
Pipe
Butt Weld
Fitting
Screwed/Socket
Fitting
Flanges
Carbon Steel A106B A234-WPB A105 A105 -20°F to 800°F
304/304LSS
2
A312-T304 A403-WP304 A182-F304 A182-F304 -425°F to 750°F
316/316LSS A312-T316 A403-WP316 A182-F316 A182-F316 -325°F to 750°F
Low Temperature
2
Carbon Steel
A333 Gr. 6 A420-WPL6 A350-LF2 A350-LF2 -50°F to 700°F
1-1/4% Chrome
2
1/2% Moly
A335-P11 A234-WPL11 A182-F11 A182-F11 -20°F to 1100°F
Hastelloy-C276
2
N10276
B622
1
B366/B564 B366/B564 B366/B564 -325°F to 800°F
Alloy-20
2
N08020
B464
1
B366/B962 B366/B462 B366/B462 -325°F to 800°F
Monel 400
2
N04400
B-165
1
B366/B564 B366/B564 B366/B564 -325°F to 900°F
Duplex SS
2
A-790 A-815 A182-F51 A182-F51 -60°F to 600°F
2-1/4% Chrome
2
1% Moly
A335-P22 A335-P22 A182-F22 A182-F22 -20°F to 1100°F
9% Chrome
1% Moly
Vanadium
A335-P91 A234-WP91 A182-F91 A182-F91 -20°F to 1200°F
AARH (µin.) 1000-2000 500-1000 250-500 125-250 63-125 32-63 16-32
Ra (µm) 25-50 12.5-25 6.3-12.5 3.2-6.3 1.6-3.2 0.8-1.6 0.4-0.8
