Special functions
6.5.7. - Heat transfer
This is used to transfer energy from one storage to another with a pump.
6.5.7.3. - ∆ T Heat transfer
Temperature difference for heat transfer function.
When the temperature difference between HT Source and HT Drain reaches ∆T
Heat Transfer On, the relay is switched on. As sson as the difference drops to
∆T Heat Transfer Off, the relay is switched off again.
Setpointtemperature of the target storage
When this temperature is detected in the target storage, heat transfer is
switched off.
6.5.7.4. - Setpoint
This menu determines the sensor, that is placed in the source storage.
6.5.7.5. - HT Source (sensor)
This determines the sensor placed in the storage that is receiving energy from
the source storage.
Relay functions
6.5.7.6. - HT Drain (Target sensor)
6.5.7.2. - Shift Tmin
Minimum temperature in source storage to enable the heat transfer.
