7
The Temperature Difference Controller MTDC facilitates ef cient use and function
control of your solar or heating system. The device is impressive most of all for its
functionality and simple, almost self-explanatory operation. For each step in the input
process the individual entry keys are assigned to appropriate functions and explained.
The controller menu contains headwords for the measured values and settings, as well
as help texts or clearly-structured graphics.
The MTDC can be used as a temperature difference controller for the various system
variants illustrated and explained under B.5. Important characteristics of the MTDC :
• Depiction of graphics and texts in a lighted display
• Simple viewing of the current measurement values
• Analysis and monitoring of the system by means of statistical graphics,etc.
• Extensive setting menus with explanations
• Menu block can be activated to prevent unintentional setting changes
• Resetting to factory settings
B.3 About the controller
Description of controller
• Temperature Difference Controller MTDC
• 3 screws 3,5 x 35 mm and 3 plugs 6 mm for wall installation
• 6 strain relief clips with 12 screws, replacement fuse T2A / 250V slow-blow
• Installation and operating instructions MTDC
Optionally contained depending on design/order:
• PT1000 temperature sensors and immersion sleeves
Additionally available:
• Pt1000 temperature sensor, immersion sleeves, overvoltage protection,
• Datalogger with Ethernet connection
B.4 Scope of supply
B.5 Disposal and pollutants
The unit conforms to the European RoHS directive 2011/65/EU for the restriction of the
use of certain hazardous substances in electrical and electronic equipment.
Caution
The unit must not under any circumstances be disposed of with ordinary
household refuse. Dispose of the unit only at appropriate collection
points or ship it back to the seller or manufacturer.
