Sorensen DCS300-4E - Electrical Specifications for 1.2 Kw Models

Features and Specifications Sorensen DCS Series 1kW and 1.2kW Supplies
1-4 M362500-01 Rev H
1.4.2 Electrical Specifications for 1.2kW Models
Specifications are warranted over a temperature range of 0-50°C with default local sensing.
From temperatures of 50-70°C, derate output 2% per °C.
Models
8-140
10-120
20-60
33-36
40-30
50-24
60-20
80-15
100-12
150-8
300-4
600-2
Output Ratings:
Output Voltage
Output Current
Output Power
0-8V
0-140A
1200W
0-10V
0-120A
1200W
0-20V
0-60A
1200W
0-33V
0-36A
1200W
0-40V
0-30A
1200W
0-50V
0-24A
1200W
0-60V
0-20A
1200W
0-80V
0-15A
1200W
0-100V
0-12A
1200W
0-150V
0-8A
1200W
0-300V
0-4A
1200W
0-600V
0-2A
1020W
Line Regulation:
7
Voltage
Current
8 mV
140 mA
10 mV
120 mA
20 mV
60 mA
33 mV
36 mA
40 mV
30 mA
50 mV
24 mA
60 mV
20 mA
80 mV
15 mA
100 mV
12 mA
150 mV
8 mA
300 mV
4 mA
600 mV
2 mA
Load Regulation:
8
Voltage
Current
8 mV
140 mA
10 mV
120 mA
20 mV
60 mA
33 mV
36 mA
40 mV
30 mA
50 mV
24 mA
60 mV
20 mA
80 mV
15 mA
100 mV
12 mA
150 mV
8 mA
300 mV
4 mA
600 mV
2 mA
Meter Accuracy:
Voltage
Current
0.09V
1.55A
0.11V
1.3A
0.3V
0.7A
0.43V
0.46A
0.5V
0.40A
0.6V
0.34A
0.7V
0.3A
0.9V
0.25A
1.1V
0.13A
1.6V
0.09A
4.0V
0.05A
7.0V
0.021A
OVP Adjustment Range
0.4-8.8V
0.5-11V
1.0-22V
1.65-36.3V
2-44V
2.5-55V
3-66V
4-88V
5-110V
7.5-165V
15-330V
30-660V
Output Noise/Ripple(V)
9
Rms
p-p
(20Hz-20MHz)
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
5 mV
60 mV
10 mV
60 mV
15 mV
160 mV
25 mV
200 mV
50 mV
300 mV
Stability:
10
Voltage
Current
4 mV
70 mA
5 mV
60 mA
10 mV
30 mA
16.5 mV
18 mA
20 mV
15 mA
25 mV
12 mV
30 mV
10 mA
40 mV
7.5 mA
50 mV
6 mA
75 mV
4 mA
150 mV
2 mA
300 mV
1 mA
Temperature
Coefficient:
11
Voltage
Current
1.6 mV
42 mA
2 mV
36 mA
4 mV
18 mA
6.6 mV
10.8 mA
8 mV
9 mA
10 mV
7.2 mA
12 mV
6 mA
16 mV
4.5 mA
20 mV
3.6 mA
30 mV
2.4 mA
60 mV
1.2 mA
120 mV
0.6 mA
Maximum Remote
Sense Line Drop
12
Compensation/line
2V
2V
4V
4V
4V
4V
4V
4V
4V
4V
4V
4V
7
For input voltage variation over the AC input voltage range, with constant rated load
8
For 0-100% load variation, with constant nominal line voltage
9
Typical P-P noise and ripple
10
Maximum drift over 8 hours with constant line, load, and temperature, after 20-minute warm-up
11
Change in output per °C change in ambient temperature, with constant line and load
12
Line drop subtracts from the maximum available output voltage at full rated power
AC Input: 200-250 Vac at 10A rms or 100-130 Vac at 20A rms, 47-63 Hz
Maximum Voltage Differential from output to safety ground: 150 Vdc
