Sorensen DCS Series 1kW and 1.2kW Supplies Features and Specifications
M362500-01 Rev H 1-5
1.4.3 Physical Specifications
Altitude: 2000M (6562 ft.)
Storage Temperature Range: -55 to +85°C
Humidity Range: 0 to 80% Non-condensing
Time Delay from power on until output stable: 3 seconds maximum
Voltage Mode Transient Response Time: 500S recovery to 1% band for 30% step load
change from 70% to 100% or 100% to 70%
Remote Start/Stop and Interlock: TTL compatible input, Contact Closure, 12-250 Vac or
12-130 Vdc
Switching Frequency: Nominal 70 kHz typical (140 kHz output ripple)
Analog Programming Linearity: Typical error is less than 0.5% setting.
Maximum error is 1% of rated output.
Agency Approvals: Regulatory NRTL to UL 1012/CSA 107.1
CE compliant (LVD and EMC directives)
Remote Analog Programming (Full Scale Input):
Scales are selectable via an internally-mounted switch.
