Shelf tray
For storing tools, materials, cardboard boxes, etc.
• Custom division using dividers.
• Anti-slip mat.
Load capacity up to 80 kg surface load.
Adjusting installation height:
The shelf trays can be adjusted in height by 17 mm in the grid.
Adapt the distances to your requirements. The mounting bolts are screwed into insert nuts; while the
clamping nuts are clamped into the grid holes.
Removal/installation:
• Unscrew mounting bolts (A), 4 per side.
• Remove the insert nuts (B) from the grid holes (C) and move them to new height.
• Adjust shelf tray (D) to new height.
• Screw in all mounting bolts (A) per side and tighten them.
