10, 12, 12MTK User Manual
5.3: GROUP MASTER OUTPUT
CHANNEL CONTROLS > GROUP MASTER OUTPUT
5.3: GROUP MASTER OUTPUT
Group Masters control the Group output levels and
routing.
Signature 12 and 12MTK consoles have two group
masters available (post-fader) - with mixes derived from
any input channel routed to GRP 1-2. Input channel
panning or balance positions work across the group
pair, with Group 1 as left and Group 2 as right.
MST
Route the Group output to the Master Stereo mix in addition to the physical Group Outputs
Group 1 goes to the Left and Group 2 Goes to the right unless the Group Master MONO button is pressed.
MONO
Switch both Group-to-MST outputs to mono
Where a Group is routed to the Master left/right output, that contribution is derived from the sum of both Group
busses. The physical Group outputs remain separate.
FADER
Adjust the overall output level of the Group
Each group has its own fader for overall level control.
