SoundCraft Signature 12MTK User Manual

10, 12, 12MTK User Manual
5.4: MASTER STEREO OUTPUT
CHANNEL CONTROLS > MASTER STEREO OUTPUT
5.4: MASTER STEREO OUTPUT
The Master (MST) Stereo Output channel determines
the output level of the main stereo (left and right) mix
from the MST L and MST R physical outputs.
On Signature 12, input channels must be routed to the
Master Stereo Output with their MST buttons.
FADER
Adjust the overall level of the Master Stereo output
INTERVAL MUTE
Mute all channels except 11/12 (Signature 12 and 12MTK) or 9/10 (Signature 10)
A fast way of switching to only the interval or playback source, or similar, without touching any other controls.
Connect the playback device to the Stereo Playback channel (highest numbered stereo channel, RCA inputs).
Engage the INTERVAL MUTE switch when required. All other channels are muted. NOTE: Aux and Group outputs
are still active.

SoundCraft Signature 12MTK Specifications

General

Type	Analog
Channels	12
Phantom Power	Yes
Computer Connectivity	USB
USB Interface	14-in/12-out
EQ Bands	3-band
Faders	60mm
Aux Sends	3 Aux Sends
Dimensions	420mm x 360mm x 140mm
Outputs - Main	XLR, 1/4" Jack
Outputs - Other	2 Aux
Inputs - Other	2 Hi-Z Inputs
