2.3: INPUT CHANNEL ROUTING

GETTING STARTED > INPUT CHANNEL ROUTING

2.3: INPUT CHANNEL ROUTING

The diagram shows the audio signal path through an input channel - from physical input to bus sends

(Aux, FX, Mix, and so on).

Please note: The entire signal path (except for the hardware pre and output DACs) is clip-free with innite

headroom. It means that internal clipping is not introduced even by driving the EQ/Dyn to the max.

Sufciently reducing the level on the Master Channel strip will get rid of any clipping on the output.

Ui12, Ui16 User Manual

Other manuals for SoundCraft UI12

Need help?

Do you have a question about the SoundCraft UI12 and is the answer not in the manual?

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
