4.3.1: AUX MASTER
CHANNELS > AUX MASTER CHANNEL
4.3.1: AUX MASTER CHANNEL
Ui12, Ui16 User Manual
The Aux Master channel is the output path for Aux busses. In other words, the Aux 1 mix of contribu-
tions from all input channels passes through the Aux 1 Master channel before being sent out of the
physical Aux 1 output. Ui12 has four Aux busses available, and Ui16 has six. The highest-numbered
aux pairs (3/4 for Ui12 and 5/6 for Ui16) are available as physical outputs when the HEADPHONES
OUT option is set to ‘AUX’ in SETTINGS
Aux Master channels have their own EDIT channels, featuring a
GEQ (Graphic EQ) rather than a parametric EQ, and dbx AFS
2
feedback elimination (See section 5).
You can view all Aux Master channels either in the MIX screen
(scroll to right) to by selecting AUX MASTERS from the tablet
software Slideout panel or from the JUMP TO pop-up menu in
the phone software Slideout panel.

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
