SoundCraft UI12 User Guide

Ui12, Ui16 User Manual
10.1: NETWORK CONFIG
SETTINGS > NETWORK CONFIG
10.1: NETWORK CONFIG
The Ui Cong page allows you to enable/disable and edit settings for Hotspot wireless connection to
the Ui hotspot), WiFi (connection to an existing WiFi network), and LAN (wired connection via Ethernet).
There is also an Administration password change page, and a summary ‘Network State’ page.
IMPORTANT: The default administration user name is ‘admin’ and the default administration password is ‘admin’.
You will be asked for these when you touch the CONFIG button.
You can change the password using the Administrator Password page once you are in the CONFIG area.

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
