SoundCraft UI12 User Guide

Ui12, Ui16 User Manual
10.0: SETTINGS
SETTINGS
10.0: SETTINGS
LANGUAGE
ENGLISH, CHINESE, GERMAN, FRENCH, SPANISH
The default language for Ui software is English, but here you can change to Chinese or German language version.
The browser will automatically refresh when these options are selected.
NETWORK
The Network options are available for manual set-up, though the most important requirement on this page is to setup
a WiFi password. When you power on your Ui mixer, it will automatically send out a WiFi signal so you connect your
device to the Ui network, and enter your password.
MONITOR ACCESS LIMIT
This Tab/View manages access permissions - limiting feature access per user. Given that a typical setup may have
multiple users logged into the Ui software, each doing their own monitor mix, it makes sense to limit their access to
reduce the possibility of accidentally changing a front of house mix.
This feature is not password protected, it is intended as a safety measure to protect accidental corruption of your mix
by other users. It is especially helpful for setting up monitor permissions.

SoundCraft UI12 Specifications

General

Channels	12
Mic Preamps	4
Hi-Z Inputs	2
USB Playback	Yes
USB Audio Interface	2-in/2-out
Wireless Control	Yes
Mic Inputs	4 x XLR
Effects	Reverb and delay
Connectivity	Wi-Fi
Wi-Fi	Built-in
Power Supply	External
Dimensions	177mm x 297mm
Weight	2.29 kg
Line Inputs	4 x XLR/TRS combo jacks (shared with mic inputs), 2 x RCA (L/R)
Control	Remote control via HTML5 compatible web browser
