4 INSTALLATION STEP 1 b
SETTING THE
HIGH PO WERLHIGH CURRENT SWITCH
The High Power/High Current switch allows the REFERENCE amplifier to be
one of two types of amps:
either producing maximum power at higher
impedances (perfect for satellites) or at lower impedances (usually with multiple
subwoofers).
The circuit operates by selecting a set of power supply voltage rails best suited
to your particular application.
One is a higher voltage “tap” optimized for high
impedance applications while the other is lower voltage designed to provide
more current, Unlike other amplifiers, Soundstream’s REFERENCE amplifiers
can be configured to drive virtually any impedance and make maximum power!
1 R Stereo
l/2 n Stereo
(2 fI Bridged)
(1 R Bridged)
REFERENCE 200
High Power
25 x 2 50x2 100x2 n/a
Watta
(50x1) (100 x 1)
(200 x 1)
High Current
12.5 x 2 25x2 50x2 100x2
Watts
(25x1)
(50 x 1) (100 x 1) (200 x 1)
REFERENCE 300
High Power
75x2 150x2 150x2 nla
Watta
(150 x 1) (300 x 1) (300 x 1)
High Current
37.5 x 2
75x2
150x2 150x2
Watta
(75 x 1) (150 x 1) (300 x 1) (300x1)
REFERENCE 500
High Power
125x2
250x2
250x2
n/a
Watts
(250 x 1) (500 x 1)
(500 x 1)
High Current
62.5 x 2 125x2 250x2 250x2
Watts
(125 x 1) (250 x 1)
(500 x 1) (500x1)
If you blow fuses with the REFERENCE amplifiers, switch to the High Current
mode.
If the problein persists, it is likely that the amplifier is seeing a dead
short, either in the speaker wire or in the speaker itself.
before blowing multi$e fused
RecUQ the problem
