PROTECTION CIRCUITRY
Your REFERENCE amplifier is protected against both overheating and short
circuits by means of the following circuits:
l Main power supply fuses
l Smart Power Supply Thermal Rollback activating at 85°C.
l A fail-safe thermal protection circuit activating at 95°C.
Your amplifier also incorporates an innovative Fault Diagnosis system that
identifies a blown power supply fuse.
NOTE: If you experience b/own main power supply fuses, DO NOT increase
values beyond the original fuse value! Doing so will void your warranty and
may damage your amplifier.
PROBLEM
No sound and LEDs are not lit
Fault LED is lit
Repeatedly blown amp fuse,
frequent activation of Smart Power
Supply Circuit
CAUSE
l no power or ground at amp
0 no remote turn-on signal
l blown fuse near battery
l amp power supply fuse is blown
or missing
l check speaker configuration,
amp may be in “High Power”
mode, put amp into “High
Current” mode if speaker load is
less than 2 ohms (see p.12,
“Setting High Power/High Current
Switch”)
l speaker or leads may be shorted
l verify adequate amplifier
ventilation
SERVICE
Your Soundstream REFERENCE amplifier is protected by a limited warranty.
Please read the enclosed warranty card.
18
