Soundstream Reference 200 - Db;Octave Passive Crossover Chart

112 dB/OCTAVE
PASSIVE CROSSOVER CHART
12 dWoctave hilsh pass
12 dB/octave low pass
KEY
Ll = high quality (DCR c 1 ohm) inductor/coil
Cl = non-polarized 50 v (or greater) capacitor
FREQ.
80 Hz
100 Hz
130 Hz
200 Hz
260 Hz
400 Hz
600 Hz
800 Hz
1000 Hz
1200 Hz
1600 Hz
4000 Hz
2 ohms
Ll Cl
5.5 mH
4.7 mH
3.3 mH
2.2 mH
1.8mH
1.1 mH
0.75 mH
0.5 mH
0.47 mH
0.33 mH
0.27 mH
0.10 mH
680 pF
560 pF
400 pF
300 pF
200 pF
150 pF
100 pF
68 pF
50 pF
44 pF
30 pF
15 wF
4 ohms
Ll Cl
11 mH
9.1 mH
6.8 mH
4.7 mH
3.6 mH
2.2 mH
1.5mH
1.0 mH
0.9 mH
0.75 mH
0.50 mH
0.22 mH
8
330 pF
270 pF
200 pF
15opF
100 pF
68 )rF
47 pF
33 pF
27 pF
22 FF
15pf
6.8 pF
8 ohms
Ll Cl
22 mH
18mH
15mH
9.1 mH
6.8 mH
4.7 mH
3.0 mH
2.0 mH
1.8mH
1.5 mH
1.0 mH
0.47 mH
180 pF
150 pF
100 pF
75 pF
50 pF
33 pF
26 pF
15pF
13pF
11 pF
6.8 pF
3.3 pF
