10
1. RCA Inputs - 3 Channel and 4 Channel RCA inputs.
2. RCA Inputs - 1 Channel and 2 Channel RCA inputs.
3. Input Levels - Input level control variable from 500mV to 4V.
4. High Pass Filter Control Adjustment- Frequency adjustment control for the
High Pass Filter for satellite CH1&2(L & R).
5. High Pass Filter Control Adjustment- Frequency adjustment control for the
High Pass Filter for satellite CH3&4.
6. Low Pass Filter Control Adjustment- Frequency adjustment control for the
Low Pass Filter for CH1&2(L & R).
7. Low Pass Filter Control Adjustment- Frequency adjustment control for the
Low Pass Filter for CH3&4.
8. Low Pass Filter Control Adjustment- Frequency adjustment control for the
Low Pass Filter for CH5.
9. Selectable X-Over HPF/FULL/LPF
10. Bass EQ Control “Boost” Adjustment - Varies from 0 to + 18 dB of boost when the Bass
Control circuit is engaged.
11. Speaker connection Terminal - Speaker connections for satellite CH3&4.
12. Speaker connection Terminal - Speaker connections for satellite CH1&2(L & R).
13. Speaker connection Terminal - Speaker connections for satellite CH5
14. REMOTE - Remote turn - on input from the head unit. Accepts +12V.
15. GND - Main ground connection. Bolt to a clean chassis point in the vehicle.
16. +12V - Connected to a fuse or circuit breaker, then to the battery’s positive
terminal.
17. FUSES - Satellite channels power supply fuses. Warring: Replace only with
the same value fuses!
18. Power LED - Indicates amplifier power.( Power:Green / Protection:Red )
19. RCA Inputs - 5 Channel RCA inputs.
20. RCA Inputs - R Channel and L Channel RCA inputs.
21. Subsonic/Bass Control Adjustment - Frequency adjustment
control for the Bass Control filter or the Sub Sonic filter.
22. AUXILIARY OUTPUT - The Aux outputs offer amplifiers easy, unlimited system expansion.
Routing signal from a source unit, pre-amplifier or equalizer is a matter of
routing RCA' s into the RCA inputs and out through the AUX outputs to the next amplifier.
KEY TO CALLOUTS
